Suntsu is proud to announce that we have added power inductors to our product offering, as they are an essential component of voltage regulator topology [2].
Suntsu’s SMD power inductors are manufactured with a magnetic shielded structure. This helps them achieve excellent resistance to EMI (Electro-Magnetic Interference), low DCR, and high rated current. In a DC-DC converter, the inductor’s DC resistance is a primary source of conduction loss, so minimizing DCR directly improves power-conversion efficiency [1]. The products were designed with lightweight and small form factors that are ideal for all designs, including high-density board applications.
Suntsu power inductors are available in surface-mount packaging with multiple package sizes. Operating temperature is -40~125°C, and the product is AEC-Q200 compliant [3]. This ensures that it can be used in buck converters, laptops, displays, and automotive applications, as well as in network communication equipment.
Suntsu Power Inductors
| Series | Image | SMT Package Size Range | Throughhole Package Size Range | Tolerance | Operating Temperature | Inductance Range | Reel | Key Feature | Datasheet |
|---|---|---|---|---|---|---|---|---|---|
| SP0420 |  | Standard SMT | 4.4x4.2x1.8mm | ±20% | -40°C ~ 125°C | 0.10µH - 10.00µH | 2000 | Low Loss, High Efficiency, Wide Application Frequency |  |
| SP0530 | | Standard SMT | 5.4x5.2x2.8mm | ±20% | -40°C ~ 125°C | 0.22µH - 22.00µH | 2000 | Low Loss, High Efficiency, Wide Application Frequency | |
| SP0730 | | Standard SMT | 7.25x6.6x2.8mm | ±20% | -40°C ~ 125°C | 0.10µH - 33.00µH | 1000 | Low Loss, High Efficiency, Wide Application Frequency | |
| SP0740 | | Standard SMT | 7.25x6.6x3.8mm | ±20% | -40°C ~ 125°C | 0.13µH - 47.00µH | 1000 | Low Loss, High Efficiency, Wide Application Frequency | |
| SP1040 | | Standard SMT | 11.5x10.0x3.8mm | ±20% | -40°C ~ 125°C | 0.15µH - 82.00µH | 800 | Low Loss, High Efficiency, Wide Application Frequency | |
| SD1280 |  | SMT, Shiled/Drum | 12.0x12.0x7.8mm | ±20%, ±30% | -40°C ~ 125°C | 1.40µH - 1000.00µH | 500 | Low DCR, High Rated Current | |
Key features include
- AEC-Q200 compliant
- Low loss, High efficiency, Wide application Frequency
- Light weight design to save space and suitable
for high density SMT - Core material: Alloy Powder
- Moisture Sensitivity Level 1
- Operating temperature of -40°C ~ 125°C
Applications include
- Automotive Electronics
- Converter
- Laptop
- Display
- Communication Equipment
If you have any questions about this product or anything else we offer, please do not hesitate and reach out to a representative. We’re here to help you create what’s next!
Need more information? Please contact us with any questions.
References
[1] Coilcraft. “Choosing Inductors for Energy Efficient Power Applications” Available at: https://www.coilcraft.com/en-us/resources/application-notes/choosing-inductors-for-energy-efficient-power-appl/
[2] NextPCB. “Power Inductor Selection Guide: Inductance, DCR & PCB Footprint” Available at: https://www.nextpcb.com/blog/power-inductor-selection-guide-pcb
[3] Aker. “AEC-Q200 Rev-E” Available at: https://aker-usa.com/aec-q200-rev-e
