Intel Cyclone 10 FPGAs

The Intel® Cyclone® 10 GX device family is a groundbreaking series of field-programmable gate arrays (FPGAs) that combine high performance with exceptional power efficiency, all within a low-cost 20 nm architecture. These devices significantly surpass their predecessors in core, transceiver, and input/output performance, making them ideal for applications requiring high bandwidth and cost sensitivity. Versatile and adaptable, the Cyclone® 10 GX FPGAs cater to various industries, including telecommunications, automotive, industrial automation, and consumer electronics, offering engineers a reliable solution that meets the demands of modern high-performance applications while staying budget-friendly.

Key Features and Capabilities

Cyclone® 10 GX FPGAs are built on TSMC’s 20 nm process technology and feature an enhanced core architecture to deliver twice the performance of the previous generation of low-cost FPGAs.

loader-icon
  • The Cyclone® 10 GX uses Adaptive Logic Modules (ALMs) as the fundamental components of the logic fabric. The ALM design remains consistent with the prior generation, ensuring efficient logic function implementations.
  • Each Logic Array Block (LAB) comprises 16 Logic Elements (LEs), which are the smallest units of logic in the architecture.
  • Users can configure up to 25% of the available LABs as memory LABs (MLAB), allowing for versatility in design.

Cyclone® 10 GX devices contain two types of memory blocks:

  • M20K blocks: Each M20K block provides 20 Kb of dedicated memory, offering substantial on-chip resources.
  • MLABs: Configured from LABs, MLABs provide 640 bits of memory functionality within the logic fabric, effectively utilizing the available resources.

Cyclone® 10 GX FPGAs are equipped with variable-precision DSP blocks that support both fixed-point and floating-point arithmetic, making them suitable for a variety of applications requiring complex mathematical computations.

These devices feature a sophisticated hierarchical clock network architecture, designed based on Intel’s global, regional, and peripheral clock structures. This setup ensures efficient clock distribution and synchronization throughout the FPGA.

The I/O capabilities of the Cyclone® 10 GX include highly configurable general-purpose inputs/outputs (GPIOs). Each I/O bank hosts 48 GPIOs, complemented by a high-efficiency hard memory controller, which enhances data transfer and connectivity options.

Cyclone® 10 GX FPGAs boast high-speed transceivers that facilitate high bandwidth and low latency communication. They can support various data rates, reaching up to 12.5 Gbps in chip-to-chip interactions and up to 6.6 Gbps for backplane connections.

Cyclone® 10 GX devices support various configuration schemes, including Active Serial (AS), Passive Serial (PS), Fast Passive Parallel (FPP), and JTAG. Cyclone 10 GX devices can also be configured through PCIe using Configuration via Protocol (CvP).

  • Partial Reconfiguration: This feature allows users to modify sections of the FPGA while keeping other parts operational, greatly enhancing design flexibility.
  • Power Management: Various power management techniques are integrated to reduce overall power consumption without compromising performance.
  • SEU Mitigation: The Cyclone® 10 GX devices come equipped with robust SEU error detection and correction circuitry, ensuring reliable operation in environments prone to radiation or other disturbances.

9k+

FPGAs
Available

l
Source Intel Parts

FPGAs Ready Now

l
SHOP INTEL FPGAS

Applications

Industrial

These devices excel in machine vision systems, providing real-time processing capabilities that enhance automation and quality control. They are also integral to robotics, facilitating advanced control and sensor integration for a variety of robotic applications. Additionally, they support programmable logic controllers (PLCs) and drivers, ensuring efficient operation in manufacturing environments by enabling seamless communication and control over industrial processes.

Broadcast

In the realm of professional audiovisual production, Intel Cyclone 10 GX devices deliver the necessary performance for high-definition video processing and streaming. They offer robust solutions for video mixing, encoding, and real-time video analytics, meeting the demanding requirements of modern broadcasting and live event production.

Benefits

Enhanced Performance

The Intel Cyclone 10 GX boasts a state-of-the-art core architecture that delivers outstanding performance, achieving approximately double the processing capabilities compared to earlier generations of low-cost FPGAs. This significant jump in performance makes it ideal for high-demand applications.

High Bandwidth

These devices are equipped with integrated transceivers that facilitate high-bandwidth communication, enabling data transfer rates of up to 12.5 Gbps. This capability is crucial for applications requiring rapid data processing and large data flows, such as video processing and telecommunications.

Versatile Integration

Cyclone 10 GX FPGAs provide enhanced logic integration, featuring robust hard IP blocks tailored for various applications. Among these are variable-precision DSP blocks, embedded memory, and hard memory controllers, which allow for more efficient design and faster system performance.

Power Efficiency

One of the standout aspects of the Cyclone 10 GX is its advanced power-saving features combined with a power-optimized architecture. This design results in significantly lower power consumption, making it an excellent choice for energy-sensitive projects and applications.

Flexible Configuration

These FPGAs support a range of configuration options, allowing designers to unleash their creativity. Features such as partial reconfiguration permit changes to the system while it remains operational, providing flexibility in adapting to new requirements or enhancing performance without downtime.

Conclusion

The Intel Cyclone 10 GX FPGAs are engineered to deliver an impressive balance of performance, versatility, and affordability, making them an ideal choice for a diverse range of high-bandwidth applications. Equipped with advanced signal processing capabilities, these FPGAs support various protocols and data rates, enabling efficient handling of complex tasks in demanding embedded systems. Their flexible architecture allows for easy customization to meet specific project requirements, while their cost-effective nature ensures a competitive advantage in budget-sensitive environments. As a result, the Cyclone 10 GX series stands out as a powerful solution for applications such as video processing, industrial automation, and telecommunications, where reliability and processing speed are paramount.
