Intel Stratix FPGAs

Intel’s Stratix 10 FPGAs and SoCs mark a remarkable leap in the realm of high-performance programmable logic, showcasing cutting-edge technology that significantly surpasses earlier models. These advanced devices provide exceptional processing power and flexibility, making them ideal for a diverse array of complex applications, from data centers and telecommunications to research and development. With their ability to handle intricate computations and adapt to various operational demands, Stratix 10 components empower engineers and developers to innovate with greater efficiency and effectiveness. As a result, they are poised to drive the next wave of technological advancements.

Key Features and Capabilities

Stratix 10 devices stand out in the field of field-programmable gate arrays (FPGAs) and system-on-chips (SoCs) due to a suite of advanced features that enhance both their performance and versatility:

Advanced Process Technology

At the forefront of innovation, Stratix 10 FPGAs and SoCs are constructed using Intel's cutting-edge 14 nm Tri-Gate (FinFET) technology. This marks a significant leap from the earlier generation, the Stratix V FPGAs, which relied on the 28 nm TSMC planar transistor technology. This transition not only increases the number of transistors that can be packed onto a chip but also improves overall efficiency.

Enhanced Architecture

These devices feature the Intel Hyperflex core architecture, which is equipped with Hyper-Registers in the interconnect. This new architecture represents a departure from the traditional design seen in Stratix V FPGAs, leading to substantially enhanced core performance. With the ability to operate at speeds of up to 1 GHz, Stratix 10 devices can handle demanding applications with ease.

High-Speed Transceivers

Designed for high-performance data transfer, Stratix 10 devices boast impressive transceiver capabilities. The GX and SX variants support data rates of up to 28.3 Gbps, while the TX devices push the boundaries even further. With advanced PAM4 technology, these devices can achieve data rates of up to 57.8 Gbps, in addition to NRZ transceivers operating at speeds of up to 28.9 Gbps. This makes them ideal for applications requiring rapid and reliable data communication.

Integrated Processor

A notable advancement in the Stratix 10 family is the inclusion of a hard processor core in select SoCs. The quad-core 64-bit Arm Cortex-A53 processor not only streamlines processing tasks but is also optimized for high performance per watt. This efficiency helps to significantly reduce power consumption compared to the Stratix V FPGAs, which lacked such an integrated core.

Logic Density

Stratix 10 devices offer a diverse range of logic densities tailored to suit various application needs. They provide options with logic elements that range from 400,000 to a substantial 10.2 million. This flexibility allows developers to select the right device for their specific requirements, whether for simple tasks or complex computations.

DSP Capabilities

The digital signal processing (DSP) capabilities of Stratix 10 devices are remarkable, achieving up to 10 tera floating-point operations per second (TFLOPS) of IEEE 754 single-precision floating-point calculations. This exceptional performance is crucial for applications that require intensive numerical computations.

AI Tensor Block

Pushing the boundaries of artificial intelligence (AI) acceleration, the Intel Stratix 10 NX FPGAs are equipped with AI Tensor Blocks. These specialized blocks enable the execution of AI designs at impressive rates, achieving up to 143 INT8 Tera Operations Per Second (TOPS) and an astonishing 286 INT4 TOPS. This makes them particularly suitable for machine learning and deep learning applications.

9k+

FPGAs
Available

Source Intel Parts

FPGAs Ready Now

SHOP INTEL FPGAS

Applications

Cognitive Computing

Stratix 10 devices leverage advanced algorithms and machine learning techniques, enabling systems to mimic human cognitive functions such as perception, reasoning, and problem-solving. This is critical for applications in artificial intelligence and natural language processing.

High-Performance Accelerators

Designed to speed up computation-intensive tasks, Stratix 10 FPGAs can serve as accelerators for various applications including finance, scientific simulations, and large-scale data analytics, providing significant boosts in processing speed and efficiency.

Enabling New Network Infrastructure

With the growing demands for high-speed connectivity and data processing, Stratix 10 devices can be integrated into next-generation network infrastructures, supporting technologies such as 5G and beyond with their high bandwidth and low latency capabilities.

OTN/Data Center Interconnect

Stratix 10 FPGAs facilitate optical transport networks (OTN) and data center interconnect (DCI) solutions, ensuring efficient data transmission across various mediums. Their flexibility allows for rapid adaptation to evolving data traffic patterns, resulting in enhanced network performance.

Radar

The high processing power and agility of Stratix 10 FPGAs make them well-suited for advanced radar applications. They are capable of real-time signal processing, enabling enhanced detection and tracking capabilities in both civil and military applications.

ASIC Prototyping and Emulation

Intel Stratix 10 devices can be utilized for fast prototyping and emulation of ASIC designs, allowing engineers to test and validate their designs before moving to silicon production. This accelerates the development cycle and reduces time-to-market.

Cyber Security

In the realm of network security, Stratix 10 FPGAs can be deployed for robust intrusion detection and prevention systems. Their ability to process large volumes of data in real-time enables organizations to identify and mitigate threats effectively, ensuring a secure network environment.

Benefits

Increased Throughput

The advanced architecture and process technology lead to remarkable enhancements in performance and throughput compared to earlier models.

Enhanced Design Functionality

Higher clock frequencies allow for narrower bus widths and smaller IP sizes, optimizing FPGA resources for improved design capabilities.

Improved Power Efficiency

The architecture facilitates design consolidation that lowers power consumption. Additionally, Intel Stratix 10 devices are designed with low upset rates and offer various options for low-power operation.

Versatile Connectivity

With support for high-speed transceivers—including 400G Ethernet options and heterogeneous 3D System-in-Package (SiP) integration—these devices enable high-bandwidth communication. Some Stratix 10 models are the first FPGAs to incorporate Intel Ultra Path Interconnect (UPI) for direct coherent connections to Intel Xeon Scalable processors and feature PCIe hard IP configurations up to Gen4 x16 at 16 Gbps.

Maximum Memory Bandwidth

These FPGAs deliver impressive memory bandwidth and support both serial and parallel external memory interfaces.

Algorithm Flexibility

The OpenCL platform, along with a software front-end for security and flow control, paired with an integrated ARM Cortex-A53 hard processor system, offers great flexibility for various algorithms.

Application Optimization

Specialized features such as hardened single-precision floating-point DSP blocks and AI Tensor Blocks enhance optimization for particular applications. The architecture of the AI Tensor Block is specifically tuned for common matrix-matrix or vector-matrix operations seen in a variety of AI tasks, ensuring efficiency for both small and large matrices.

Diverse Options

A variety of logic densities, transceiver counts, package choices, and speed grades provide designers with the needed flexibility to choose the devices that best meet their unique requirements.

Enhanced Security

The security features support secure cloud solutions, including bitstream authentication and authorization, decryption, secure key provisioning and storage, along with tamper monitoring capabilities.

Reliability

Intel Stratix 10 FPGAs and SoCs are built for high reliability and come equipped with SEU mitigation features.

Conclusion

Intel Stratix 10 FPGAs and SoCs are an exceptional choice for applications with high performance and demanding requirements, offering unmatched integration and connectivity. These advanced devices harness state-of-the-art technology and innovative architectural designs to empower engineers in creating sophisticated systems tailored to various industries. With a comprehensive range of features, Stratix 10 devices provide the versatility needed for everything from data processing and telecommunications to automotive and aerospace applications. Their robust capabilities facilitate the development of cutting-edge solutions that push the boundaries of what’s possible in engineering, making them an indispensable tool for modern technological advancements.
