DF2116VT20MV
IC MCU 16BIT 128KB FLASH 144TQFP
| Part Description | H8S/2000 H8® H8S/2100 Microcontroller IC 16-Bit 20MHz 128KB (128K x 8) FLASH 144-TQFP (16x16) |
|---|
| Product Category | Microcontrollers |
|---|---|
| Manufacturer | Renesas Electronics Corporation |
| Manufacturing Status | Obsolete |
| Leadtime | N/A |
| Datasheet | |
| Quantity | 957 Available |
Specifications
| Part Package | 144-TQFP |
|---|---|
| Device Package | 144-TQFP (16×16) |
| Mounting Method | Surface Mount |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Core Processor: | H8S/2000 |
| Core Size: | 16-Bit |
| Speed: | 20MHz |
| Connectivity: | I2C, LPC, SCI |
| Peripherals: | POR, PWM, WDT |
| Number of I/O: | 112 |
| Program Memory Size: | 128KB (128K x 8) |
| Program Memory Type: | FLASH |
| RAM Size: | 8K x 8 |
| Voltage – Supply (Vcc/Vdd): | 3V ~ 3.6V |
| Data Converters: | A/D 16x10b |
| Oscillator Type: | Internal |
Environmental
| REACH Compliance | REACH Unknown |
|---|---|
| RoHS Compliance | Not applicable |
| Moisture Sensitivity Level | N/A |
| ECCN | EAR99 |
| HTS Code | 0000.00.0000 |
