FSA1259K8X
IC SWITCH SPST-NOX2 850MOHM US8
| Part Description |
2 Circuit IC Switch 1:1 850mOhm US8 |
|---|---|
| Quantity | 796 Available (as of May 6, 2026) |
| Product Category | Analog Switches, Multiplexers, Demultiplexers |
|---|---|
| Manufacturer | onsemi |
| Manufacturing Status | Obsolete |
| Datasheet |
Specifications
| Part Package | 8-VFSOP (0.091″”, 2.30mm Width) |
|---|---|
| Device Package | US8 |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Switch Circuit: | SPST – NO |
| Multiplexer/Demultiplexer Circuit: | 1:1 |
| Number of Circuits: | 2 |
| On-State Resistance (Max): | 850mOhm |
| Channel-to-Channel Matching (ΔRon): | 50mOhm |
| Voltage – Supply, Single (V+): | 1.65V ~ 5.5V |
| Switch Time (Ton, Toff) (Max): | 7.5ns, 11ns |
| -3db Bandwidth: | 240MHz |
| Charge Injection: | 15pC |
| Channel Capacitance (CS(off), CD(off)): | 21pF |
| Current – Leakage (IS(off)) (Max): | 10nA |
| Crosstalk: | -73dB @ 1MHz |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | Unknown |
| Moisture Sensitivity Level | 1 (Unlimited) |
| ECCN | EAR99 |
| HTS Code | 8542.39.0001 |
