ATSAMV71Q19B-CBT
IC MCU 32BIT 512KB FLSH 144TFBGA
| Part Description | ARM® Cortex®-M7 SAM V71 Microcontroller IC 32-Bit Single-Core 300MHz 512KB (512K x 8) FLASH 144-TFBGA (10x10) |
|---|
| Product Category | Microcontrollers |
|---|---|
| Manufacturer | Microchip Technology |
| Manufacturing Status | Active |
| Leadtime | 49 Weeks |
| Datasheet | |
| Quantity | 386 Available |
Specifications
| Part Package | 144-TFBGA |
|---|---|
| Device Package | 144-TFBGA (10×10) |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Core Processor: | ARM® Cortex®-M7 |
| Core Size: | 32-Bit Single-Core |
| Speed: | 300MHz |
| Connectivity: | CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SPI, SSC, UART/USART, USB |
| Peripherals: | Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT |
| Number of I/O: | 114 |
| Program Memory Size: | 512KB (512K x 8) |
| Program Memory Type: | FLASH |
| RAM Size: | 256K x 8 |
| Voltage – Supply (Vcc/Vdd): | 3V ~ 3.6V |
| Data Converters: | A/D 24x12b; D/A 2x12b |
| Oscillator Type: | Internal |
| Grade: | Automotive |
| Qualification: | AEC-Q100 |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | ROHS3 Compliant |
| Moisture Sensitivity Level | 3 (168 Hours) |
| ECCN | 5A992C |
| HTS Code | 8542.31.0001 |
