MSP430F5304IPTR
IC MCU 16BIT 8KB FLASH 48LQFP
| Part Description | MSP430 CPUXV2 MSP430F5xx Microcontroller IC 16-Bit 25MHz 8KB (8K x 8) FLASH 48-LQFP (7x7) |
|---|
| Product Category | Microcontrollers |
|---|---|
| Manufacturer | Texas Instruments |
| Manufacturing Status | Active |
| Leadtime | 12 Weeks |
| Datasheet | |
| Quantity | 1247 Available |
Specifications
| Part Package | 48-LQFP |
|---|---|
| Device Package | 48-LQFP (7×7) |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Core Processor: | MSP430 CPUXV2 |
| Core Size: | 16-Bit |
| Speed: | 25MHz |
| Connectivity: | I2C, IrDA, LINbus, SCI, SPI, UART/USART |
| Peripherals: | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Number of I/O: | 31 |
| Program Memory Size: | 8KB (8K x 8) |
| Program Memory Type: | FLASH |
| RAM Size: | 6K x 8 |
| Voltage – Supply (Vcc/Vdd): | 1.8V ~ 3.6V |
| Data Converters: | A/D 8x10b |
| Oscillator Type: | Internal |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | ROHS3 Compliant |
| Moisture Sensitivity Level | 3 (168 Hours) |
| ECCN | EAR99 |
| HTS Code | 8542.31.0001 |
