DRA712BGGCBDRQ1
| Part Description |
ARM® Cortex®-A15 Microprocessor IC DRA71x 1 Core, 32-Bit 400MHz 538-FCBGA (17x17) |
|---|---|
| Quantity | 156 Available (as of October 8, 2026) |
| Product Category | Microprocessors |
|---|---|
| Part Series | Jacinto DRA71x |
| Manufacturer | Texas Instruments |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 26 Weeks |
| Datasheet |
Specifications & Environmental
| Co-Processors/DSP | ARM® Cortex®-M4, BB2D, GPU, IVA | Core Processor | ARM® Cortex®-A15 | Device Package | 538-FCBGA (17x17) | ||
|---|---|---|---|---|---|---|---|
| Display & Interface Controllers | HDMI, LCD | ECCN | N/A | Ethernet | 10/100/1000Mbps (1), 1Gbps (2) | ||
| Grade | Automotive | Graphics Acceleration | Yes | HTS Code | N/A | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Mounting Method | Surface Mount | Mounting Type | Surface Mount | ||
| Number of Cores/Bus Width | 1 Core, 32-Bit | Operating Temperature | -40°C ~ 125°C (TJ) | Package / Case | 538-LFBGA, FCBGA | ||
| RAM Controllers | DDR3, DDR3L | REACH Compliance | REACH Unknown | RoHS Compliance | ROHS3 Compliant | ||
| Security Features | Cryptography, Debug Security, Device Identity, Isolation Firewalls, Secure Boot, Secure Storage, Software IP Protection | Speed | 400MHz | Supplier Device Package | 538-FCBGA (17×17) | ||
| USB | USB 2.0 (2), USB 3.0 (1) | Voltage – I/O | 1.35V, 1.5V, 1.8V, 3.3V |
Overview of DRA712BGGCBDRQ1 – ARM Cortex-A15 Microprocessor
The DRA712BGGCBDRQ1 is an ARM® Cortex®-A15 based microprocessor from the Jacinto DRA71x family, featuring a single 32-bit Cortex-A15 core running at 400 MHz. Designed for advanced embedded infotainment and automotive applications, it integrates multimedia, graphics, memory and extensive I/O to support navigation, HMI and in-vehicle multimedia systems.
With on-chip accelerators, a variety of high‑bandwidth interfaces and automotive qualification (AEC‑Q100), this device targets designs that require integrated video/graphics processing, secure operation, and wide operating temperature capability.
Key Features
- Core and Processing Single ARM® Cortex®-A15 32‑bit core at 400 MHz; includes co‑processors such as ARM® Cortex®-M4, BB2D 2D graphics accelerator, GPU (PowerVR™ SGX544) and IVA for video/image processing.
- Memory and Storage Supports DDR3 and DDR3L via an EMIF memory controller; up to 512 KB on-chip L3 RAM and support for up to 2 GB DDR across a single chip select as described in the DRA71x series documentation.
- Video and Graphics Full‑HD video support (1920 × 1080p, 60 fps), HDMI encoder (HDMI 1.4a/DVI 1.0 compliant), 2D/3D graphics acceleration and video processing engine for multimedia and display pipelines.
- Connectivity and I/O Multiple high‑speed interfaces including USB 3.0 (SuperSpeed) dual-role, USB 2.0 dual-role and OTG, PCI Express 3.0 lanes, Gigabit Ethernet (up to two external ports), MIPI CSI‑2 camera interface, CAN 2.0B, MMC/SD/SDIO and numerous UART, SPI, I2C and GPIO options.
- Security Hardware crypto accelerators and DMA, secure boot, secure storage, device identity, isolation firewalls, JTAG lock and software IP protection for secure system operation.
- Automotive Qualification and Temperature AEC‑Q100 qualification with an operating temperature range of −40 °C to 125 °C, suitable for automotive-grade designs requiring extended temperature operation.
- Package and Mounting 538‑ball FCBGA package, 17 mm × 17 mm, 0.65 mm ball pitch; surface-mount BGA for compact board integration.
Typical Applications
- Automotive Infotainment — Integrates video, audio and display pipelines with HDMI and GPU support for navigation and multimedia playback systems.
- Human‑Machine Interfaces (HMI) — Drives rich graphical user interfaces and touch displays using 2D/3D acceleration and dedicated display controllers.
- Digital Cluster and Instrumentation — Meets requirements for automotive clusters with secure boot, wide temperature range and deterministic I/O for real-time display and sensor integration.
- Navigation and Telematics — Supports high‑bandwidth connectivity (Ethernet, USB, PCIe) and camera input (MIPI CSI‑2) for navigation systems and telematics modules.
Unique Advantages
- Highly integrated multimedia subsystem: On-chip video, graphics and image processing units reduce external component count and simplify system design for infotainment applications.
- Automotive-ready qualification: AEC‑Q100 qualification and −40 °C to 125 °C operating range support deployment in automotive environments.
- Comprehensive connectivity: Native support for Gigabit Ethernet, USB 3.0/2.0, PCIe, CAN and MIPI provides flexibility for networking, storage and camera interfaces.
- Built-in security primitives: Hardware crypto, secure boot, isolation firewalls and secure storage help protect IP and system integrity in safety‑conscious designs.
- Scalable memory and performance: DDR3/DDR3L memory interface and on‑chip L3 RAM enable responsive multimedia and application performance within a compact package.
Why Choose DRA712BGGCBDRQ1?
The DRA712BGGCBDRQ1 positions itself as an integrated, automotive‑qualified processor for infotainment, HMI and vehicle display systems. Its combination of a Cortex‑A15 core, dedicated multimedia and graphics accelerators, broad high‑speed I/O and hardware security features provides a balanced platform for engineers building feature-rich, reliable automotive electronics.
Choose this device when your design requires verified automotive qualification, wide temperature operation, and on‑chip multimedia and connectivity integration that reduces BOM complexity while enabling advanced user experiences and secure operation.
Request a quote or submit an inquiry for pricing and availability to evaluate DRA712BGGCBDRQ1 for your next embedded or automotive design.
