RJ45 connectors are widely used modular interconnection devices that transmit both signals and electrical power to the devices they are connecting to via cables. Suntsu is now offering both magnetic and non-magnetic RJ45 Jacks to accommodate a vast array of market applications.
Our magnetic RJ45 jack line includes options for 10/100/1000 Base-T, LED’s, EMI fingers, and provide a highly integrated solution from cable to the ethernet physical layer. They also have great EMI noise performance and reliable connections.
Our non-magnetic RJ45 jacks, support a variety of cable entry configurations in a shielded form factor, and have a Cat 3 rating.
Key features include
- Improved EMI noise performance
- Support 10/100/1000 Base-T up to 10Gb performance speeds
- With or Without PoE function
- Extend temperature -40~85°C
- LED options
- SMT or Through-hole
Applications include
- Ethernet Switch
- Access Point
- Servers
- PLCs
- Motor Controls
- Routers
- Communication Equipment
Suntsu RJ45 Connectors
| Part No. | Image | Number of Contacts | Contact Plating | Magnetic | EMI Finger | LED | Description | Datasheet |
|---|---|---|---|---|---|---|---|---|
| SCNRJ-88GGMSEN-073I4SORTH |  | 8 | 6u" Gold Plating | Yes | Yes | No | 10/100 Base-T Single port |  |
| SCNRJ-88GGMSEGY-483I4SORTH |  | 8 | 6u" Gold Plating | Yes | Yes | Yes | 10/100 Base-T Single port | |
| SCNRJ-88GGMSNGY-073I4SORTH |  | 8 | 6u" Gold Plating | Yes | No | Yes | 10/100 Base-T Single port | |
| SCNRJ-1010GGMSEGY-073GSORTH |  | 10 | 6u" Gold Plating | Yes | Yes | Yes | 10/100 Base-T Single port | |
| SCNRJ-88GGMSEYG-073GSORTH |  | 8 | 6u" Gold Plating | Yes | Yes | Yes | 10/100 Base-T Single port | |
| SCNRJ-88GGMSNGY-076HSOVTH |  | 8 | Selective Gold Plating | Yes | No | Yes | 10/100 Base-T Single port | |
| SCNRJ-88GGMSNGY-486HSOVTH |  | 8 | 6u" Gold Plating | Yes | No | Yes | 10/100 Base-T Single port | |
| SCNRJ-1212GGMSEGY-073FSORTH |  | 12 | 6u" Gold Plating | Yes | Yes | Yes | 10/100/1000 Base-T Single port integrated module | |
| SCNRJ-88GGMSNN-073I4SORTH |  | 8 | 6u" Gold Plating | Yes | No | No | 10/100 Base-T Single port | |
| SCNRJ-1010GGMSEGY-073I4SORTH |  | 10 | 6u" Gold Plating | Yes | Yes | Yes | 10/100/1000 Base-T Single port | |
| SCNRJ-66SGNNNN-471FSORTH |  | 6 | Selective Gold Plating | No | No | No | RJ45 Jack Side Entry | |
| SCNRJ-88GGNNNN-474FSORTH |  | 8 | 6u" Gold Plating | No | No | No | RJ45 Jack Side Entry | |
| SCNRJ-88SGNNNN-474FSORTH |  | 8 | Selective Gold Plating | No | No | No | RJ45 Jack Side Entry | |
| SCNRJ-88SGNSNN-482ASORTH |  | 8 | Selective Gold Plating | No | No | No | RJ45 Jack Shielded Side Entry | |
| SCNRJ-88SGNSNN-483BSORTH |  | 8 | Selective Gold Plating | No | No | No | RJ45 Jack Shielded Side Entry | |
| SCNRJ-1010GGNSNN-484H5SORTH |  | 10 | 6u" Gold Plating | No | No | No | RJ45 Jack Shielded Side Entry | |
| SCNRJ-1010SGNSNN-484H5SORTH |  | 10 | Selective Gold Plating | No | No | No | RJ45 Jack Shielded Side Entry | |
| SCNRJ-88GGNSEN-483ESORTH |  | 8 | 6u" Gold Plating | No | Yes | No | RJ45 Jack Top Entry | |
| SCNRJ-88SGNNNN-485ASOVTH |  | 8 | Selective Gold Plating | No | No | No | RJ45 Jack Top Entry | |
| SCNRJ-88SGNSNN-486FSOVTH |  | 8 | Selective Gold Plating | No | No | No | RJ45 Jack Shielded Top Entry | |
If you have any questions about this product or anything else we offer, please do not hesitate and reach out to a representative.
We’re here to help you create what’s next!
