A40MX04-1PL68M

The A40MX04-1PL68M is a military-grade MX field programmable gate array (FPGA) supplied in a 68-lead LCC (J-lead) surface-mount package. It provides a compact, reconfigurable logic element set suitable for embedded systems that require robust temperature and voltage operating ranges.

With 547 logic elements (approximately 6,000 gates) and 57 I/O pins, this device targets designs that need moderate logic density, predictable I/O capacity and support for wide supply ranges from 3 V to 5.5 V.

Key Features

• Core Logic  547 logic elements delivering roughly 6,000 equivalent gates for implementing custom digital functions and finite-state machines.
• I/O Capacity  57 user I/O pins to connect peripherals, buses and external devices in space-constrained layouts.
• Memory  No on-chip RAM (0 total RAM bits), enabling deterministic logic usage or external memory architectures when required.
• Power  Flexible supply voltage range from 3 V to 5.5 V to accommodate common embedded power domains.
• Package and Assembly  68-LCC (J-lead) surface-mount package; supplier device package listed as 68-PLCC (24.23 × 24.23 mm) for compact board-level integration.
• Temperature and Grade  Military-grade device rated for operation from −55 °C to 125 °C for harsh-environment applications.
• Compliance  RoHS compliant for regulatory and environmental considerations.

Typical Applications

• Military and Defense Systems  Suitable for military applications that require components with a military-grade temperature range and reliability.
• Rugged Embedded Electronics  Use in embedded control and signal-processing modules operating across −55 °C to 125 °C.
• Space-Constrained Modules  Compact 68-lead LCC package with 57 I/O delivers reconfigurable logic in small form-factor assemblies.

Unique Advantages

• Military-Grade Reliability:  Specified operating range of −55 °C to 125 °C and a military grade designation support deployment in demanding environments.
• Wide Supply Voltage Range:  3 V to 5.5 V operation enables flexible power system integration across a variety of embedded platforms.
• Balanced Logic Density:  547 logic elements and ~6,000 gates provide a mid-range implementation capacity for custom glue logic and control functions.
• Compact Surface-Mount Package:  68-LCC/68-PLCC footprint allows dense PCB layouts while retaining solderable surface-mount assembly.
• Regulatory Compliance:  RoHS compliant to support environmental requirements in procurement and manufacturing.

Why Choose A40MX04-1PL68M?

The A40MX04-1PL68M delivers a practical combination of reprogrammable logic, I/O count and rugged temperature capability for applications that demand military-grade performance in a compact package. Its mid-range logic capacity and 57 I/O pins make it well suited to designs that need reliable, deterministic logic without integrated RAM.

This device is a fit for engineers and procurement teams building systems that require wide supply-voltage tolerance, surface-mount PLCC packaging, and qualified operation across extreme temperatures — offering a stable platform for long-lifecycle or harsh-environment projects.

Request a quote or submit an inquiry to obtain pricing and availability for the A40MX04-1PL68M and discuss how it can meet your project requirements.
