A42MX09-2PQG100I

The A42MX09-2PQG100I is an MX family FPGA from Microchip Technology packaged in a 100-BQFP surface-mount case. It delivers moderate logic capacity—14,000 gates and 336 logic elements—paired with 83 programmable I/O for control and interface tasks in embedded systems.

Designed for industrial applications, this device supports a wide supply range from 3 V to 5.5 V and an operating temperature range of −40 °C to 85 °C, making it suitable for a variety of industrial embedded control and I/O-centric designs.

Key Features

• Core and Logic 14,000 gates and 336 logic elements provide the programmable logic capacity needed for glue logic, protocol handling, and moderate-complexity state machines.
• Programmable I/O 83 I/O pins enable flexible interfacing to sensors, actuators, and peripheral devices in I/O-intensive applications.
• Supply Voltage Range Operates across 3 V to 5.5 V, allowing integration with common industrial and embedded power domains.
• Package and Mounting 100-BQFP (100-PQFP, 20×14) surface-mount package delivers a compact footprint for PCB-level integration.
• Temperature Grade Industrial-grade operation from −40 °C to 85 °C supports deployment in temperature-variable environments.
• Compliance RoHS compliant for environmental and manufacturing compatibility.

Typical Applications

• Industrial Control — Use for control logic, interface glue, and I/O management within industrial automation equipment where industrial temperature rating and flexible I/O are required.
• I/O Expansion and Protocol Bridging — Implement protocol adapters, buffering, or signal routing between subsystems using the device’s 83 programmable I/O.
• Embedded Logic and System Glue — Deploy as a compact programmable solution for state machines, timing control, and peripheral orchestration in embedded systems.

Unique Advantages

• Balanced Logic Density: 14,000 gates and 336 logic elements provide sufficient capacity for moderate-complexity designs without excessive board-level overhead.
• High I/O Count: 83 programmable I/O pins simplify interfacing and reduce the need for external I/O expanders.
• Wide Voltage Compatibility: 3 V to 5.5 V supply range supports integration with multiple power domains common in industrial and embedded applications.
• Industrial Temperature Range: Rated for −40 °C to 85 °C to maintain reliable operation across typical industrial thermal conditions.
• Standard Surface-Mount Package: 100-BQFP package enables dense placement and easy assembly on standard PCBs.
• RoHS Compliant: Meets environmental compliance expectations for modern electronics manufacturing.

Why Choose A42MX09-2PQG100I?

The A42MX09-2PQG100I combines moderate programmable logic capacity and a high I/O count in a compact 100-BQFP package, optimized for industrial embedded designs that require reliable operation across a wide voltage and temperature range. Its feature set targets applications needing flexible interfacing and glue logic without excessive complexity.

Backed by Microchip Technology’s MX FPGA family documentation, this device is appropriate for engineers and procurement teams seeking a RoHS-compliant, industrial-grade FPGA for control, interfacing, and embedded logic tasks where space and power-domain flexibility matter.

Request a quote or submit an inquiry to discuss availability, pricing, or to obtain additional technical documentation for the A42MX09-2PQG100I.
