A42MX16-2PQG100I
| Part Description |
MX Field Programmable Gate Array (FPGA) IC 83 100-BQFP |
|---|---|
| Quantity | 1,382 Available (as of May 4, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Microchip Technology |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 12 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 100-PQFP (20x14) | Grade | Industrial | Operating Temperature | -40°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 100-BQFP | Number of I/O | 83 | Voltage | 3 V - 5.5 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | ROHS3 Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 1232 | Number of Logic Elements/Cells | 608 | ||
| Number of Gates | 24000 | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A |
Overview of A42MX16-2PQG100I – MX Field Programmable Gate Array (FPGA) IC 83 100-BQFP
The A42MX16-2PQG100I is a Microchip MX series FPGA packaged in a 100-BQFP surface-mount package. It provides moderate logic capacity and a broad I/O count for embedded control and logic integration in industrial-temperature applications.
Key device parameters include 24,000 gates, 1,232 CLBs, 608 logic elements, 83 user I/Os, a wide supply range of 3 V to 5.5 V, and an operating temperature range of −40 °C to 85 °C.
Key Features
- Logic Capacity 1,232 CLBs and 608 logic elements, delivering a total of 24,000 gates for implementing custom logic and control functions.
- I/O and Integration 83 user I/Os to support multiple signals and peripheral connections in a single device.
- Memory Total on-chip RAM bits: 0, indicating no embedded RAM on the device.
- Power Wide voltage supply range from 3 V to 5.5 V to accommodate varied system power domains.
- Package & Mounting 100-BQFP (supplier package 100-PQFP 20×14) in a surface-mount configuration for standard PCB assembly processes.
- Operating Range & Grade Industrial grade device rated for operation from −40 °C to 85 °C.
Unique Advantages
- Moderate logic density: 24,000 gates and 1,232 CLBs provide a balance between capability and board-level complexity.
- Generous I/O availability: 83 I/Os enable multiple external interfaces and flexible signal routing without immediate need for I/O expanders.
- Wide supply compatibility: 3 V to 5.5 V operation supports integration into systems with varied power rails.
- Industrial temperature rating: −40 °C to 85 °C supports deployment in temperature-challenging environments.
- Standard surface-mount package: 100-BQFP (20×14 PQFP) supports common PCB assembly workflows and component sourcing.
Why Choose A42MX16-2PQG100I?
The A42MX16-2PQG100I positions itself as a mid-density FPGA option for designers who need configurable logic, ample I/O count, and industrial-temperature operation. Its combination of 24,000 gates, 1,232 CLBs, and 83 I/Os makes it suitable for embedded control, custom glue logic, and moderate-complexity signal processing tasks where on-chip RAM is not required.
For teams seeking a device with flexible supply voltage tolerance and a standard 100-BQFP surface-mount package, this FPGA offers a straightforward integration path with clear, verifiable specifications that support predictable system behavior and long-term deployment in industrial environments.
Request a quote or submit an inquiry to receive pricing and availability information for the A42MX16-2PQG100I.
