HD64180R1P8V

The HD64180R1P8V is an 8-bit microprocessor built around a Z180 core, supplied by Renesas and targeted at consumer embedded applications. With an 8 MHz clock rate and 5 V I/O, it delivers a straightforward, low-complexity processing option for designs that require a classic 8-bit architecture.

Packaged in a through-hole DIP format and specified for operation from 0 °C to 70 °C, this device is suited to designs where serviceability, simple integration into 5 V platforms, and RoHS compliance are priorities.

Key Features

• Core Architecture  Z180 core processor providing an established 8-bit processing architecture for control and interfacing tasks.
• Clock Speed  8 MHz operating frequency for deterministic, low-speed embedded control.
• Data Width and Cores  Single-core, 8-bit data path suitable for basic control and I/O handling.
• Voltage I/O  5 V I/O compatibility for direct integration with legacy and common 5 V peripherals.
• Package and Mounting  Through-hole DIP package (supplier device package: DIP) for ease of prototyping, repair, and retrofit in legacy boards.
• Operating Temperature  Rated for 0 °C to 70 °C operation, aligning with consumer-grade environmental requirements.
• Environmental Compliance  RoHS compliant to meet common regulatory and environmental standards.
• Graphics Acceleration  No graphics acceleration (not applicable), emphasizing its role as a general-purpose control processor.

Typical Applications

• Consumer Embedded Devices  Utilized in consumer electronics where an 8-bit Z180 core running at 8 MHz with 5 V I/O meets functional requirements.
• Legacy and Retrofit Designs  DIP package and through-hole mounting allow straightforward replacement and maintenance of legacy PCBs.
• Basic Control and I/O  Suitable for simple control, sensor interfacing, and user-interface tasks within the stated temperature and voltage limits.

Unique Advantages

• Established Z180 Core: The Z180-based architecture provides a known 8-bit instruction set and behavior for designs that require that heritage.
• 5 V I/O Compatibility: Direct interfacing to 5 V peripherals reduces the need for level translation in existing 5 V systems.
• Through-Hole DIP Packaging: Simplifies assembly, testing, and field replacement, beneficial for prototyping and repairable products.
• RoHS Compliant: Meets common environmental compliance requirements for consumer products.
• Consumer Grade Temperature Range: Specified 0 °C to 70 °C operation suitable for many consumer-facing applications.

Why Choose HD64180R1P8V?

The HD64180R1P8V is positioned for designers seeking a straightforward 8-bit solution based on the Z180 core with 5 V I/O and through-hole serviceability. Its specifications align with consumer embedded projects where simplicity, repairability, and compliance are key considerations.

Backed by Renesas manufacturing and provided in a DIP package, this microprocessor is appropriate for maintenance, retrofit, and low-complexity control designs that require predictable 8-bit operation within the stated temperature and voltage parameters.

Request a quote or contact sales to discuss HD64180R1P8V availability, pricing, and how it fits your next consumer embedded design.
