HD64180S2CP8

The HD64180S2CP8 is an 8-bit microprocessor from Renesas in the HD64180S2 series, built around a Z180 core. It provides a single 8-bit processing core running at 8 MHz with a 5 V I/O interface for embedded consumer applications.

Packaged in a CDIP through-hole form factor and qualified for consumer use, this device suits designs and repairs that require a traditional DIP footprint, RoHS compliance, and operation across a 0°C to 70°C temperature range.

Key Features

• Core Z180 core architecture with a single 8-bit processing core, offering straightforward control and data-handling for embedded tasks.
• Clock Speed 8 MHz operating frequency, suitable for control and processing workloads matched to an 8-bit microprocessor.
• Supply and I/O 5 V I/O voltage level compatibility for legacy and consumer-grade systems.
• Package & Mounting CDIP package supplied in a through-hole format, enabling easy hand-soldering, prototyping, and replacement on legacy PCBs.
• Operating Range Rated for operation from 0°C to 70°C, targeting consumer-environment deployments.
• Regulatory RoHS compliant, meeting common environmental restrictions for electronic components.

Typical Applications

• Consumer Embedded Systems Used in consumer-grade embedded devices that require an 8-bit processor with 5 V I/O and CDIP packaging.
• Legacy and Through-Hole Designs Ideal for equipment and repair scenarios where a CDIP through-hole package is required or preferred.
• Prototyping and Development Suited for development boards or prototypes that benefit from easy socketing and through-hole assembly.
• Repair and Replacement A practical choice for refurbishing or maintaining legacy consumer electronics that originally used DIP-packaged microprocessors.

Unique Advantages

• Proven Z180 Core: Provides a familiar 8-bit architecture for designs that rely on Z180-based implementations.
• Through-Hole CDIP Package: Enables simple installation, manual assembly, and drop-in replacement on legacy PCBs.
• Consumer Qualification: Specified for consumer applications and tested across a 0°C to 70°C operating range to match typical consumer environments.
• 5 V I/O Compatibility: Directly supports systems and peripheral interfaces that operate at standard 5 V logic levels.
• RoHS Compliant: Meets environmental compliance requirements for lead-free assembly and restricted substances.

Why Choose HD64180S2CP8?

The HD64180S2CP8 balances a classic Z180 8-bit core with conservative operating characteristics—8 MHz clock speed, 5 V I/O, and a CDIP through-hole package—making it well suited to consumer embedded projects, legacy equipment maintenance, and prototyping efforts that require DIP compatibility. Its RoHS compliance and consumer-grade operating range further align it with modern assembly and regulatory expectations.

This part is appropriate for designers and technicians working on consumer-class embedded systems, board repairs, or prototype builds where an 8-bit, through-hole microprocessor is preferred for ease of assembly and replacement. Choosing this component supports straightforward integration into existing 5 V systems and legacy form-factor designs.

Request a quote or submit a parts inquiry to obtain pricing and availability for the HD64180S2CP8.
