KMPC8315CVRAGDA

The KMPC8315CVRAGDA is a PowerPC e300c3-based microprocessor featuring a single 32-bit core running at 400 MHz. It is a highly integrated host processor designed for embedded applications that require balanced CPU performance, broad I/O connectivity, and on-chip system functions.

Designed for storage, networking and industrial markets, this device targets applications such as NAS, VoIP routers/gateways, WLAN systems, set-top boxes and industrial controllers by combining processing, memory interfaces and multiple high-speed peripheral controllers in a compact HBGA package.

Key Features

• Core  PowerPC e300c3 architecture, single 32-bit core at 400 MHz providing deterministic embedded processing.
• Memory Controllers  Integrated controllers for DDR and DDR2 memory to support modern system memory interfaces.
• High‑Speed Ethernet  Two 10/100/1000 Mbps Ethernet interfaces for dual Gigabit connectivity and flexible network deployment.
• SATA Storage  Two Serial ATA 3 Gbps ports for direct connection to storage devices and array controllers.
• USB  One USB 2.0 host/device interface with integrated PHY for peripheral connectivity.
• Security Engine  On-chip security capabilities including cryptography support and a random number generator; co-processor listed as Security (SEC 3.3).
• Peripheral and System Interfaces  Rich on-chip peripherals and system interfaces documented in the MPC8315E family datasheet including PCI, PCIe and common serial buses.
• Package & Mounting  620‑HBGA (29×29 mm) surface-mount package supplied in tray format for production assembly.
• Qualification  Industrial-grade qualification suitable for embedded industrial deployments.

Typical Applications

• Network Attached Storage (NAS)  Dual SATA ports and Gigabit Ethernet make the device suitable for NAS systems and storage gateways.
• Routers & Gateways  Dual Gigabit Ethernet and USB connectivity support VoIP routers, gateways and network appliances.
• Wireless Infrastructure  Used in intelligent WLAN and wireless access point designs where integrated processing and network I/O are required.
• Consumer Set‑Top Boxes  Integration of CPU, memory controllers and I/O enables media gateway and set-top box implementations.
• Industrial Controllers  Industrial qualification and on-chip peripherals support control and communication tasks in automation and control systems.

Unique Advantages

• Integrated system connectivity: Multiple high-speed interfaces (dual Gigabit Ethernet, dual SATA, USB 2.0) reduce external controller count and simplify board design.
• Security-capable platform: On-chip cryptographic functions and a random number generator provide building blocks for secure data handling and communications.
• Memory flexibility: Support for DDR and DDR2 memory controllers enables designers to choose memory technology to match cost and performance targets.
• Compact production package: 620-HBGA (29×29) surface-mount package balances high pin count with a small PCB footprint for space-constrained systems.
• Industrial qualification: Specified industrial qualification helps address reliability and deployment expectations for industrial applications.
• Documented family ecosystem: Part of the MPC8315 series with comprehensive hardware documentation and published technical specifications to aid system design and validation.

Why Choose KMPC8315CVRAGDA?

The KMPC8315CVRAGDA delivers a compact, integrated embedded processing solution that balances 400 MHz PowerPC performance with a broad set of on-chip interfaces and security features. Its combination of dual Gigabit Ethernet, dual SATA, USB, and DDR/DDR2 memory support targets system designs that require networked storage, gateway functions, or industrial communications in a single device.

Being part of the MPC8315 family, this device is supported by detailed hardware documentation and is positioned for developers and procurement teams building storage, networking and industrial products that need a documented, industrial‑qualified microprocessor with extensive I/O integration.

Request a quote or submit an inquiry to receive pricing and availability information for the KMPC8315CVRAGDA and to discuss application-specific requirements.
