A3PN030-ZQNG68

The A3PN030-ZQNG68 is a ProASIC3 nano FPGA IC from Microchip Technology designed for compact, surface-mount digital designs. It provides a predictable logic fabric with 768 logic elements (cells) and approximately 30,000 gates for implementing glue logic, control functions, and custom I/O handling.

Packaged in a 68-VFQFN exposed pad (68-QFN, 8×8) and specified for commercial-grade operation, this device is suited to applications that require a small footprint, moderate logic capacity, and a 1.425 V to 1.575 V core supply range.

Key Features

• Core and Logic 768 logic elements (cells) and 30,000 gates provide a compact, deterministic logic fabric for combinational and sequential logic implementations.
• I/O Count 49 user I/Os to support a variety of peripheral interfacing and glue-logic tasks in constrained designs.
• Embedded Memory Total RAM bits: 0 (no on-chip RAM).
• Power Core voltage supply range: 1.425 V to 1.575 V, enabling straightforward integration with matched power rails.
• Package & Mounting 68-VFQFN exposed pad package (supplier device package: 68-QFN 8×8) in a surface-mount form factor for compact PCB layouts and thermal grounding via the exposed pad.
• Temperature & Compliance Commercial operating temperature range: −20 °C to 85 °C. RoHS-compliant construction supports environmental requirements for commercial products.

Typical Applications

• Consumer Electronics Implement interface bridging, control logic, and custom peripherals where board space and a moderate number of I/Os are priorities.
• Industrial Automation Handle glue logic, state machines, and I/O aggregation in control panels and localized controllers within the commercial temperature range.
• Communications & Networking Provide protocol adaptation, header manipulation, or signal conditioning in compact network devices requiring deterministic logic resources.
• Test & Measurement Create custom timing, control, and sequencing logic for bench equipment and production test fixtures.

Unique Advantages

• Compact, manufacturable package: 68-VFQFN exposed pad with an 8×8 QFN footprint reduces PCB area while supporting reliable surface-mount assembly.
• Deterministic logic capacity: 768 logic elements and 30,000 gates give predictable resource availability for mapping control and interface functions.
• Straightforward power requirements: Narrow core voltage range (1.425 V–1.575 V) simplifies supply design and rail selection.
• Commercial-grade suitability: Rated for −20 °C to 85 °C operation and RoHS compliance for mainstream electronic products.
• Surface-mount ready: Exposed pad package supports thermal grounding and compact assembly for production environments.

Why Choose A3PN030-ZQNG68?

The A3PN030-ZQNG68 delivers a balanced combination of compact packaging, a clearly defined logic resource set, and straightforward power and thermal characteristics for commercial embedded designs. It is well suited to engineers and teams building space-constrained boards that require reliable, deterministic logic and a moderate number of I/Os.

Backed by Microchip Technology documentation and support materials, this ProASIC3 nano device offers designers a predictable integration path and long-term availability for products in consumer, communications, industrial automation, and test applications.

Request a quote or submit an inquiry for A3PN030-ZQNG68 to receive pricing, lead-time, and availability information.
