M2GL025-VF256

The M2GL025-VF256 is an IGLOO2 Field Programmable Gate Array (FPGA) IC providing substantial programmable logic and embedded memory in a compact 256-LFBGA package. With 27,696 logic elements and approximately 1.13 Mbits of on-chip RAM, this device targets designs requiring mid-range logic density, integrated memory, and a sizable I/O count.

Designed as a surface-mount, commercial-grade FPGA, the M2GL025-VF256 supports a wide supply range (1.14 V to 2.625 V) and an operating temperature of 0 °C to 85 °C, and it is RoHS compliant.

Key Features

• Core Logic 27,696 logic elements (LEs) for implementing custom digital logic and moderate-complexity designs.
• Embedded Memory Approximately 1.13 Mbits (1,130,496 bits) of on-chip RAM for buffering, state storage, and local data processing.
• I/O Capacity 138 I/O pins to support multiple interfaces and peripheral connections in a single FPGA package.
• Power Supply Range Flexible supply voltage from 1.14 V to 2.625 V to accommodate a range of system power architectures.
• Package and Mounting 256-LFBGA package (supplier device package: 256-FPBGA, 14×14) in a surface-mount form factor for compact board designs.
• Temperature and Grade Commercial grade with an operating temperature range of 0 °C to 85 °C for standard embedded applications.
• Environmental Compliance RoHS compliant to meet common environmental and manufacturing requirements.

Typical Applications

• Embedded System Logic Implement custom control logic and glue-logic functions using the device’s 27,696 logic elements and embedded RAM.
• Interface and Protocol Bridging Use the 138 I/O pins to bridge between multiple digital interfaces or to aggregate peripheral signals on a single FPGA.
• Data Buffering and Local Processing Leverage approximately 1.13 Mbits of on-chip RAM for buffering, small FIFOs, and local data manipulation without external memory.
• Compact Board Designs The 256-LFBGA package supports space-constrained PCBs while maintaining significant logic and I/O resources.

Unique Advantages

• High Logic Density: 27,696 logic elements provide substantial programmable capacity for mid-range digital designs.
• Significant On-Chip Memory: Approximately 1.13 Mbits of embedded RAM reduces dependency on external memory for many applications.
• Generous I/O Count: 138 I/Os enable integration of multiple peripherals and interfaces without additional interface chips.
• Flexible Power Options: Broad supply voltage range (1.14 V–2.625 V) allows integration into varied system power domains.
• Compact, Surface-Mount Package: 256-LFBGA (256-FPBGA, 14×14) supports compact PCB layouts while providing full device capability.
• RoHS Compliant: Meets common environmental requirements for modern electronics manufacturing.

Why Choose M2GL025-VF256?

The M2GL025-VF256 balances substantial programmable logic, embedded memory, and a high I/O count in a compact 256-LFBGA surface-mount package. Its commercial-grade operating range and flexible supply voltage make it well suited for a variety of embedded designs that require integrated logic and local memory without extensive external components.

This device is appropriate for engineers and teams building mid-density FPGA-based systems who need a combination of logic capacity, on-chip RAM, and numerous I/Os in a space-efficient package, backed by RoHS compliance.

If you would like pricing or availability, request a quote or submit an inquiry to receive further information and a formal quotation for the M2GL025-VF256.
