R7F701402EA14AFB#KA0
IC MCU 32BIT 4MB FLASH 144LFQFP
| Part Description | RH850G3M RH850/D1L Microcontroller IC 32-Bit Single-Core 120MHz 4MB (4M x 8) FLASH 144-LFQFP (20x20) |
|---|
| Product Category | Microcontrollers |
|---|---|
| Manufacturer | Renesas Electronics Corporation |
| Manufacturing Status | Obsolete |
| Leadtime | N/A |
| Quantity | 1672 Available |
Specifications
| Part Package | 144-LQFP |
|---|---|
| Device Package | 144-LFQFP (20×20) |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Core Processor: | RH850G3M |
| Core Size: | 32-Bit Single-Core |
| Speed: | 120MHz |
| Connectivity: | CANbus, EBI/EMI, Ethernet, I2C, LINbus, SCI, SPI, SSI, UART/USART, USB |
| Peripherals: | DMA, I2S, LCD, LVD, POR, PWM, WDT |
| Number of I/O: | 103 |
| Program Memory Size: | 4MB (4M x 8) |
| Program Memory Type: | FLASH |
| EEPROM Size: | 64K x 8 |
| RAM Size: | 512K x 8 |
| Voltage – Supply (Vcc/Vdd): | 2.7V ~ 5.5V |
| Data Converters: | A/D 16x12b |
| Oscillator Type: | Internal |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | ROHS3 Compliant |
| Moisture Sensitivity Level | 3 (168 Hours) |
| ECCN | OBSOLETE |
| HTS Code | N/A |
