FWIXP420BD

The FWIXP420BD is an Intel XScale microprocessor IC featuring a single 32‑bit core clocked at 533 MHz in a 492‑BGA (35x35) surface‑mount package. It is designed for embedded applications that require integrated network and communications interfaces alongside a general‑purpose processor core.

On‑chip resources include an SDRAM controller, dual 10/100 Mbps Ethernet ports with MII, a USB 1.1 port, and dedicated communications and math co‑processor engines. The device is commercial grade, RoHS compliant, and specified for operation from 0 °C to 70 °C.

Key Features

• Core Single XScale 32‑bit core operating at 533 MHz for deterministic embedded processing.
• Memory Controller Integrated SDRAM controller to support external volatile memory for application and buffering needs.
• Network Interfaces Dual 10/100 Mbps Ethernet ports with MII support for media interface connectivity and networked data transport.
• Peripheral Connectivity USB 1.1 port for host/peripheral connectivity and external device interfacing.
• Co‑processors On‑chip communications and network processor engine, plus math/multiply‑accumulate capabilities to offload specialized tasks.
• Power and I/O I/O voltage specified at 3.3 V to match common embedded interface levels.
• Package and Mounting 492‑BGA (35x35) package, surface mount, providing a compact footprint for board integration.
• Grade and Temperature Commercial grade with an operating temperature range of 0 °C to 70 °C.
• Environmental Compliance RoHS compliant.

Typical Applications

• Networking Appliances Dual 10/100 Ethernet and MII support make this device suitable for routers, switches, and other small network appliances.
• Embedded Communication Controllers Integrated communications co‑processors and SDRAM controller enable packet processing and protocol handling in embedded systems.
• Commercial Embedded Devices USB 1.1 and standard 3.3 V I/O accommodate peripheral connectivity in consumer and commercial embedded products.
• Gateways and Access Equipment Combined Ethernet ports and network engine capabilities support gateway functions and traffic management in access equipment.

Unique Advantages

• Integrated Networking Interfaces: Dual 10/100 Mbps Ethernet and MII simplify board design for networked products.
• Dedicated Offload Engines: Communications and math co‑processors reduce CPU load for protocol and compute‑intensive tasks.
• Compact BGA Package: 492‑BGA (35x35) surface‑mount package conserves PCB area while supporting dense designs.
• Standard Voltage I/O: 3.3 V I/O compatibility with common embedded peripherals and transceivers.
• Commercial‑Grade, RoHS Compliant: Meets commercial temperature range requirements and environmental compliance for modern product programs.

Why Choose FWIXP420BD?

The FWIXP420BD positions a 533 MHz XScale core with integrated memory control and multiple network interfaces into a compact 492‑BGA package, making it well suited for embedded networking and communications designs that demand a balance of processing capability and interface integration. Its dedicated communications and math co‑processors let designers offload specialized tasks while the SDRAM controller and standard I/O levels simplify system integration.

This RoHS‑compliant, commercial‑grade device is appropriate for manufacturers building routers, gateways, and other embedded networked products where board space, interface integration, and deterministic embedded processing are priorities.

Request a quote or submit an inquiry to receive pricing and availability for the FWIXP420BD. Provide your quantity and delivery requirements to get a tailored response.
