Z84C0008PEG

The Z84C0008PEG is a Zilog Z80 microprocessor IC featuring a single 8-bit core running at 8 MHz. Designed for embedded applications, it offers a classic Z80 architecture in a through-hole 40‑DIP package for straightforward integration into board-level and legacy systems.

With 5 V I/O, industrial grade qualification and an operating temperature range of −40 °C to 100 °C, this device targets embedded and industrial designs that require a reliable, easily serviceable 8-bit MPU solution.

Key Features

• Core and Architecture Single Z80 core, 8-bit bus width suitable for traditional microprocessor architectures and embedded control tasks.
• Clock Speed 8 MHz operating frequency for timing and control applications that align with this performance envelope.
• Voltage I/O 5 V I/O levels for compatibility with standard 5 V logic systems.
• Package & Mounting 40‑PIN DIP (0.620", 15.75 mm) in a through‑hole PDIP package for easy prototyping, assembly and field servicing.
• Industrial Grade & Temperature Range Industrial grade device rated for operation from −40 °C to 100 °C for use in demanding environments.
• Standards Compliance RoHS compliant to meet common environmental requirements.
• Graphics Acceleration No graphics acceleration; intended for control and processing tasks rather than graphics workloads.

Typical Applications

• Embedded Control Control and monitoring tasks in microcontroller-style embedded systems that utilize an 8-bit Z80 core.
• Industrial Automation Industrial control equipment and instrumentation where an industrial-grade temperature range and 5 V I/O are required.
• Legacy System Maintenance Repair, refurbishment or replacement in legacy designs that rely on Z80-based MPU form factors and through‑hole packages.
• Prototyping & Development Breadboard and development work benefiting from the 40‑DIP through‑hole package for rapid iteration and easy socketing.

Unique Advantages

• Proven Z80 Architecture: Single-core Z80 design provides a familiar instruction set and development model for engineers working with classic 8-bit systems.
• Through‑Hole 40‑DIP Packaging: Standard PDIP footprint (0.620", 15.75 mm) simplifies prototyping, manual assembly and on-site replacement.
• Industrial Temperature Range: Rated from −40 °C to 100 °C to support operation in a wide range of environmental conditions.
• 5 V I/O Compatibility: Native 5 V signaling eases integration with existing 5 V logic and peripheral components.
• RoHS Compliant: Conforms to RoHS requirements for environmental compliance in manufacturing.

Why Choose Z84C0008PEG?

Z84C0008PEG combines the established Z80 single‑core 8‑bit architecture with industrial-grade specifications and a serviceable through‑hole 40‑DIP package. It is positioned for embedded and industrial applications where a reliable, easy-to-integrate 8‑bit MPU is required, and where operating temperature and 5 V I/O compatibility matter.

Backed by Zilog's Z80 lineage and available documentation, this MPU suits designers maintaining legacy platforms, building industrial controllers, or developing hardware that benefits from a proven 8‑bit processor in a standard PDIP form factor.

Request a quote or submit a purchase inquiry for Z84C0008PEG to check current availability and pricing for your next embedded or industrial design.
