AGL250V5-CSG196

The AGL250V5-CSG196 is an IGLOO family flash FPGA in a 196-TFBGA (CSBGA) package, offering 6,144 logic elements, 36,864 bits of on-chip RAM and 143 user I/Os. Based on the IGLOO low-power flash architecture, this device targets applications that require reprogrammable logic, low power modes, mixed-voltage I/O support and integrated clock conditioning.

Designed for commercial-grade systems, the device combines nonvolatile flash configuration, low-power features such as Flash*Freeze and Low Power Active operation, and on-chip clock circuitry to simplify system integration and power management.

Key Features

• Logic Capacity  6,144 logic elements (cells) supporting designs up to approximately 250,000 system gates.
• Embedded Memory  36,864 bits of on-chip RAM for user logic storage and data buffering.
• I/O and Standards  143 user I/Os with multi-voltage support for 1.2V, 1.5V, 1.8V, 2.5V and 3.3V signaling and advanced I/O options available in AGL250-class devices.
• Low-Power Modes  Flash*Freeze ultra-low-power retention mode (as low as 5 µW) and Low Power Active (static idle) operation (from 12 µW) to minimize system standby power while retaining FPGA content.
• Nonvolatile Flash Configuration  Reprogrammable flash-based configuration that retains programmed design when powered off and supports in-system programming (ISP).
• Clock Conditioning and PLL  Integrated clock conditioning circuitry with PLL support and configurable phase/multiply/divide capabilities for system timing.
• Power and Operating Range  Core supply specified at 1.425 V to 1.575 V; device rated for commercial operating temperatures from 0 °C to 70 °C.
• Package and Mounting  196-TFBGA (CSBGA) surface-mount package, supplier device package 196-CSP (8×8), RoHS compliant.

Typical Applications

• Battery-powered and portable systems  Use Flash*Freeze and Low Power Active modes to extend battery life while maintaining system responsiveness and configuration retention.
• Data interfaces and bridging  143 I/Os and advanced I/O capabilities make the device suitable for high-speed interface control, protocol bridging and mixed-voltage signaling tasks.
• Embedded control and user interfaces  6,144 logic elements and on-chip RAM provide capacity for real-time control, state machines, and peripheral aggregation in compact systems.

Unique Advantages

• Low standby power with retention  Flash*Freeze mode delivers micro-watt class retention, enabling always-on features with minimal energy draw.
• Nonvolatile, reprogrammable configuration  Flash-based configuration removes the need for external configuration memory and preserves design across power cycles.
• Flexible I/O and mixed-voltage support  Bank-selectable voltages and wide I/O standard support simplify interfacing to diverse peripherals and system domains.
• Integrated clock management  On-chip PLL and clock conditioning reduce external component count for clocking and timing requirements.
• Compact, surface-mount packaging  196-TFBGA CSBGA package provides a small footprint for space-constrained designs while supporting solder reflow assembly.

Why Choose AGL250V5-CSG196?

The AGL250V5-CSG196 blends IGLOO-series low-power architecture and nonvolatile flash configuration with a mid-range logic capacity and ample I/O, making it a pragmatic choice for commercial embedded designs that need reprogrammable logic with strong power-management options. Its combination of 6,144 logic elements, 36,864 bits of RAM and 143 I/Os supports a wide range of control, interface and processing tasks within a compact surface-mount package.

This device is suited to designers seeking a reprogrammable single-chip solution with integrated clock conditioning, low-power standby modes and commercial temperature operation. The flash-based configuration and RoHS compliance offer predictable manufacturing and lifecycle advantages for product lines that require field reprogrammability and low-power operation.
