EP4CE15E22C8

The EP4CE15E22C8 is a Cyclone IV E family FPGA in a 144‑LQFP exposed pad package, providing 15,408 logic elements and 81 general-purpose I/O pins for commercial embedded designs. It integrates on‑chip RAM and a mid-range logic capacity suitable for custom logic, interface, and control applications within commercial temperature environments.

Designed for surface-mount assembly and RoHS compliance, this device operates from a 1.15 V to 1.25 V core supply and supports an operating temperature range of 0 °C to 85 °C. Documentation is provided via the Cyclone IV Device Handbook series.

Key Features

• Core Architecture Cyclone IV E FPGA family device providing programmable logic for custom digital designs.
• Logic Capacity 15,408 logic elements to implement moderate-complexity state machines, datapaths, and glue logic.
• Embedded Memory 516,096 bits of on‑chip RAM (approximately 0.5 Mbits) for buffering, FIFOs, and small lookup tables.
• I/O Resources 81 general-purpose I/O pins to support peripheral interfaces, buses, and external device control.
• Power Supply Core supply range of 1.15 V to 1.25 V, allowing designs to target the Cyclone IV E recommended operating conditions.
• Package & Mounting 144‑LQFP exposed pad (20 × 20 mm) surface-mount package for PCB integration with thermal pad support.
• Operating Range Commercial temperature rating: 0 °C to 85 °C, suitable for a wide range of commercial applications.
• Environmental Compliance RoHS compliant for regulatory and manufacturing considerations.

Typical Applications

• Commercial Embedded Systems — Use the 15,408 logic elements and on‑chip RAM to implement custom control logic, protocol bridging, and interface supervision in commercial equipment.
• Interface & Glue Logic — 81 I/O pins accommodate diverse peripheral connections and bus translations between system components.
• Prototyping and Development — Moderate logic and memory capacity are appropriate for proof‑of‑concept FPGA implementations and iterative hardware development.

Unique Advantages

• Balanced Logic and Memory: 15,408 logic elements paired with approximately 0.5 Mbits of embedded RAM enable integration of control, buffering, and data-path functions on a single device.
• Flexible I/O Count: 81 I/O pins provide connectivity options for a variety of peripherals without immediate need for external multiplexing.
• Compact, Serviceable Package: 144‑LQFP exposed pad format (20×20 mm) supports surface-mount assembly and improved thermal management via the exposed pad.
• Commercial Temperature Rating: Rated for 0 °C to 85 °C operation, aligning with mainstream commercial product requirements.
• Standards‑Friendly Manufacturing: RoHS compliance simplifies integration into lead‑free manufacturing processes.
• Documented Family Support: Device is part of the Cyclone IV E family and referenced in the Cyclone IV Device Handbook documentation set.

Why Choose EP4CE15E22C8?

The EP4CE15E22C8 delivers a practical balance of logic capacity, embedded memory, and I/O density in a compact 144‑LQFP exposed pad package for commercial embedded applications. Its 15,408 logic elements and 516,096 bits of on‑chip RAM support a wide range of mid‑complexity digital functions while the 81 I/O pins enable flexible system interfacing.

This device is appropriate for designers and procurement teams targeting commercial-grade FPGA solutions that require documented family support and RoHS‑compliant manufacturing. The EP4CE15E22C8 is positioned for projects that need integrated logic, local memory, and reliable package options within a defined operating voltage and temperature envelope.

Request a quote or submit a procurement inquiry to obtain pricing and availability for the EP4CE15E22C8.
