M2GL005S-1TQ144I

The M2GL005S-1TQ144I is an IGLOO2 field programmable gate array from Microchip Technology, offered in a 144-LQFP package. It combines a moderate logic capacity with embedded RAM and a substantial I/O count in an industrial-grade surface-mount package.

Designed for embedded and industrial applications, this device provides reprogrammable logic, approximately 0.72 Mbits of on-chip RAM and 84 I/O, supporting designs that require configurable logic, local memory, and reliable operation across a wide operating temperature range.

Key Features

• Logic Capacity  6060 logic elements for implementing custom combinational and sequential logic functions.
• Embedded Memory  Approximately 0.72 Mbits of on-chip RAM (719,872 total RAM bits) for buffering, lookup tables, and small data storage.
• I/O  84 general-purpose I/O pins to interface with sensors, peripherals, and external devices.
• Power Supply  Flexible supply range from 1.14 V to 2.625 V to accommodate a variety of core and I/O voltage domains.
• Package and Mounting  144-LQFP package (supplier device package: 144-TQFP (20x20)), surface-mount for compact PCB implementations.
• Industrial Temperature Range  Rated for operation from −40 °C to 100 °C, suitable for industrial environments.
• Regulatory Compliance  RoHS compliant.

Typical Applications

• Industrial Control  Implement custom control logic, state machines, and interface bridging for equipment operating across industrial temperature ranges.
• Sensor and Data Aggregation  Aggregate sensor inputs and perform local buffering using the device’s I/O and embedded RAM for preprocessing before forwarding to a host.
• Communications and Protocol Bridging  Use programmable logic to implement protocol translators or custom I/O handling where 84 I/O pins and on-chip memory are useful.
• Embedded Prototyping  Rapidly iterate hardware functions and validate custom logic in small-form-factor surface-mount designs.

Unique Advantages

• Balanced Logic and Memory:  6060 logic elements paired with approximately 0.72 Mbits of embedded RAM provide a practical balance for mid-range logic and local data storage needs.
• High I/O Count:  84 I/O pins enable direct interfacing with multiple peripherals and sensors without immediate need for external multiplexing.
• Industrial-Grade Robustness:  Rated from −40 °C to 100 °C for reliable operation in industrial environments.
• Compact, Surface-Mount Package:  144-LQFP (144-TQFP 20x20) allows compact PCB layouts while maintaining accessibility to a substantial number of pins.
• Flexible Power Envelope:  Supports a broad supply range (1.14 V to 2.625 V) for integration into a variety of system power architectures.

Why Choose M2GL005S-1TQ144I?

The M2GL005S-1TQ144I positions itself as a practical IGLOO2 FPGA option where a balance of logic elements, embedded memory, and I/O density is required in an industrial-grade, surface-mount package. Its combination of 6060 logic elements, approximately 0.72 Mbits of on-chip RAM, and 84 I/O pins makes it suitable for embedded systems that need reprogrammable logic and local buffering within a compact footprint.

For designers targeting industrial and embedded markets, this device offers reprogrammability for design flexibility, an operating range that supports harsher environments, and packaging suited for standard PCB assembly. It is a candidate for projects that require configurable logic and reliable operation across a wide temperature range.

Request a quote or submit an inquiry to receive pricing and availability information for the M2GL005S-1TQ144I. Provide your quantity and delivery requirements to obtain a tailored response.
