M2GL005S-TQ144

The M2GL005S-TQ144 is a commercial-grade IGLOO2 Field Programmable Gate Array (FPGA) from Microchip Technology. It provides a mid-range balance of programmable logic capacity, embedded memory, and I/O count in a 144-pin LQFP surface-mount package suitable for a range of embedded applications.

With 6,060 logic elements, approximately 0.72 Mbits of on-chip RAM and 84 general-purpose I/O, this device is targeted at commercial embedded designs that require moderate logic density, configurable I/O, and standard assembly compatibility.

Key Features

• Logic Capacity  6,060 logic elements for implementing custom combinational and sequential logic.
• Embedded Memory  719,872 bits of on-chip RAM—approximately 0.72 Mbits—providing local storage for FIFOs, buffers, and state data.
• I/O  84 general-purpose I/O pins to interface with external peripherals and signals.
• Power Supply  Operates from a voltage supply range of 1.14 V to 2.625 V, enabling flexible integration into varied power architectures.
• Package & Mounting  144-LQFP package (supplier device package: 144-TQFP, 20×20) with surface-mount mounting for standard PCB assembly processes.
• Operating Range  Commercial operating temperature range of 0 °C to 85 °C suitable for office and consumer environments.
• Regulatory  RoHS compliant, meeting common lead-free and hazardous substance requirements for commercial products.

Typical Applications

• Commercial Embedded Systems  Implement control logic and peripheral interfacing where 6,060 logic elements and 84 I/O provide the required functionality.
• Interface Bridging and Protocol Conversion  Use the FPGA to glue diverse digital interfaces together, leveraging available I/O and on-chip RAM for buffering.
• Custom Logic Acceleration  Offload specific processing tasks into programmable logic to optimize system partitioning within commercial products.

Unique Advantages

• Balanced Logic and Memory:  6,060 logic elements paired with approximately 0.72 Mbits of embedded RAM give designers a practical resource mix for mid-complexity designs.
• Ample I/O Count:  84 I/O pins simplify direct connections to sensors, actuators, and peripheral devices without the need for external expanders.
• Flexible Supply Range:  Support for 1.14 V to 2.625 V supplies allows integration into a variety of standard power domains.
• Surface-Mount LQFP Package:  The 144-LQFP (144-TQFP, 20×20) package supports common PCB assembly workflows and simplifies mechanical integration.
• Commercial Grade and RoHS Compliant:  Designed for commercial applications and compliant with RoHS requirements for lead-free manufacturing.

Why Choose M2GL005S-TQ144?

The M2GL005S-TQ144 positions itself as a practical IGLOO2 FPGA choice for commercial embedded projects that need a moderate combination of logic, memory, and I/O in a standard surface-mount package. Its specification set supports designers who require configurable logic resources and local RAM without moving to larger, higher-cost devices.

Backed by Microchip Technology manufacturing, this FPGA is suited for teams building commercial products that demand predictable temperature and supply ranges, package compatibility with common assembly processes, and RoHS compliance.

Request a quote or submit an RFQ to receive pricing and availability for the M2GL005S-TQ144. Our team can assist with lead times and order placement.
