M2GL010T-1VF400I
| Part Description |
IGLOO2 Field Programmable Gate Array (FPGA) IC 195 933888 12084 400-LFBGA |
|---|---|
| Quantity | 216 Available (as of May 5, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Microchip Technology |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 10 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 400-VFBGA (17x17) | Grade | Industrial | Operating Temperature | -40°C – 100°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 400-LFBGA | Number of I/O | 195 | Voltage | 1.14 V - 2.625 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | RoHS non-compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 12084 | Number of Logic Elements/Cells | 12084 | ||
| Number of Gates | N/A | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 933888 |
Overview of M2GL010T-1VF400I – IGLOO2 FPGA, 400-LFBGA
The M2GL010T-1VF400I is an IGLOO2 family Field Programmable Gate Array from Microchip Technology that integrates fourth-generation flash-based FPGA fabric with high-performance communications interfaces. The device provides 12,084 logic elements, 933,888 bits of on-chip RAM (approximately 0.93 Mbits), and up to 195 user I/Os in a 400-LFBGA package.
Designed for applications that require low power, reliability, security and high-speed I/O, this industrial-grade FPGA supports a wide voltage supply range (1.14 V to 2.625 V) and an operating temperature range of -40°C to 100°C.
Key Features
- Core Architecture Fourth-generation flash-based FPGA fabric with efficient 4-input LUTs and carry chains for improved performance and power efficiency (IGLOO2 family).
- Logic Capacity Approximately 12,084 logic elements to implement mid-range programmable logic functions.
- Embedded Memory Total on-chip RAM of 933,888 bits (approximately 0.93 Mbits). The IGLOO2 family also offers larger embedded SRAM and micro SRAM block options at the family level.
- DSP and Mathblocks Family-level DSP resources include up to 240 fast mathblocks with 18×18 signed multiplication, 17×17 unsigned multiplication and a 44-bit accumulator for signal-processing workloads.
- High-Speed Serial & Memory Interfaces IGLOO2 family capabilities include up to 16 SERDES lanes with support for XGXS/XAUI, native SERDES, and PCIe endpoint cores, plus DDRx memory controllers (LPDDR/DDR2/DDR3) with up to 333 MHz clock rates.
- I/O and Voltage 195 user I/Os with multi-standard support and a voltage supply range of 1.14 V to 2.625 V to accommodate varied interface standards.
- Security Features Family-level design security includes encrypted user key and bitstream loading, device certificate for supply-chain assurance, anti-tamper features and zeroization; premium devices add NRBG, AES-256, SHA-256 and ECC engines.
- Clocking Resources Multiple embedded oscillators and up to eight Clock Conditioning Circuits (CCCs) with integrated analog PLLs for flexible clock generation and distribution.
- Package & Temperature 400-LFBGA (supplier device package: 400-VFBGA 17×17), surface-mount package, industrial-grade operation from -40°C to 100°C.
Typical Applications
- High-Speed Communications Implement protocol interfaces and PHY layers using SERDES lanes, PCIe endpoints and XAUI/XGMII extensions available in the IGLOO2 family.
- Signal Processing and DSP Offload math-intensive functions to on-chip mathblocks and embedded RAM for tasks such as filtering, transforms and real-time processing.
- Memory-Intensive Embedded Systems Integrate DDR2/DDR3 memory controllers and on-chip RAM to support buffering, data aggregation and complex embedded applications.
- Secure and Reliable Systems Use built-in design and data security features for protected bitstream loading, device authentication and anti-tamper requirements.
Unique Advantages
- Flash-Based, Low-Power Architecture Fourth-generation flash fabric contributes to the IGLOO2 family’s low-power and reliable operation.
- Integrated High-Speed Interfaces On-chip SERDES lanes and DDRx controllers reduce external components and simplify high-throughput system design.
- Balanced Logic and Memory The combination of ~12k logic elements and ~0.93 Mbits of on-chip RAM supports mixed control, protocol and data-path implementations.
- Built-In Security Options Family-level encrypted bitstream, device certificate and advanced cryptographic primitives on premium devices help protect IP and secure deployments.
- Industrial Temperature and Dense Packaging 400-LFBGA surface-mount package and -40°C to 100°C rating support rugged embedded and industrial applications.
Why Choose M2GL010T-1VF400I?
The M2GL010T-1VF400I delivers a balanced combination of mid-range logic capacity, embedded memory and family-level high-performance interfaces in an industrial-grade, low-power IGLOO2 FPGA. It is suited for engineers building secure, reliable embedded systems that require DSP acceleration, high-speed serial links and flexible memory interfacing.
As part of the IGLOO2 family from Microchip Technology, this device provides scalable architectural features—clocking resources, SERDES options and security capabilities—that help streamline design integration and long-term platform planning.
Request a quote or submit your requirements to receive pricing and availability information for M2GL010T-1VF400I.
