XC4028XL-09BG256C

The XC4028XL-09BG256C is a commercial-grade Field Programmable Gate Array (FPGA) from AMD in the XC4000E/X family. It provides a balance of on-chip logic, embedded RAM, and a high I/O count in a 256-ball BGA package suitable for surface-mount PCB assembly.

With 2,432 logic elements, 32,768 bits of embedded RAM and 205 I/Os, this device targets commercial embedded designs that require moderate programmable logic capacity combined with extensive external interfacing and a compact package footprint.

Key Features

• Logic Capacity – 2,432 logic elements organized for implementing custom digital logic; device data also lists 1,024 configurable logic blocks.
• Embedded Memory – 32,768 bits of on-chip RAM for small FIFOs, state storage, and buffering needs.
• I/O Density – 205 user I/Os to support broad connectivity with external peripherals and subsystems.
• Gate Count – Approximately 28,000 gates, enabling integration of moderate-complexity digital functions into a single device.
• Power – Operates from a 3.0 V to 3.6 V supply range to match common commercial power rails.
• Package & Mounting – 256‑BBGA package (supplier device package: 256‑PBGA, 27×27) optimized for surface mount assembly.
• Operating Range – Commercial temperature range from 0 °C to 85 °C for general-purpose commercial applications.
• Compliance – RoHS compliant, supporting lead‑free assembly and environmental regulations.

Typical Applications

• Commercial Embedded Systems – Implement custom control logic and data paths in products where a commercial-grade FPGA is required.
• I/O Expansion and Glue Logic – Use the device’s 205 I/Os to consolidate interfacing, bus bridging, and signal conditioning tasks on a single FPGA.
• Prototyping and Development – Leverage the on-chip logic and RAM to prototype digital designs and validate interfaces before scaling to production.
• Compact PCB Designs – The 256-ball BGA package provides a high pin count in a compact footprint for space-constrained boards.

Unique Advantages

• High I/O Count: 205 user I/Os enable broad external interfacing without additional multiplexing or external expanders.
• Moderate Logic Integration: 2,432 logic elements and ~28,000 gates allow consolidation of multiple discrete functions into a single programmable device, reducing BOM complexity.
• On‑Chip RAM: 32,768 bits of embedded memory provide local storage for FIFOs, buffering, and small data tables, improving system responsiveness.
• Commercial Temperature Range: Rated for 0 °C to 85 °C, suitable for general commercial environments and applications.
• RoHS Compliant: Supports lead-free manufacturing and aligns with common environmental requirements.
• Compact BGA Package: 256‑BBGA (256‑PBGA, 27×27) enables a high pin density in a space-efficient form factor.

Why Choose XC4028XL-09BG256C?

The XC4028XL-09BG256C offers a practical combination of logic resources, embedded RAM, and a large I/O complement in a commercially rated FPGA. Its specifications make it well suited to designers who need moderate programmable logic capacity alongside extensive interfacing in a compact surface-mount package.

This device is ideal for engineers building commercial embedded products that benefit from on-chip memory, a high I/O count, and a standardized BGA footprint—delivering integration and board-level space savings while adhering to RoHS requirements.

Request a quote or submit a purchase request to get pricing and availability for the XC4028XL-09BG256C. Our team will provide the information you need to move your design forward.
