LS1023AXE7QQB

The LS1023AXE7QQB is a QorIQ Layerscape microprocessor based on a dual ARM® Cortex®‑A53 64‑bit core complex running at 1.6 GHz. It is designed for embedded networking and industrial infrastructure applications that require a compact, high‑performance processor with flexible I/O and hardware security features.

With integrated memory controllers for DDR3L/DDR4, multi‑port Ethernet support, SATA and USB 3.0, and industrial qualification, the LS1023A delivers a balanced combination of CPU performance, I/O integration and system security for small‑form‑factor communications and control devices.

Key Features

• Core Dual ARM® Cortex®‑A53 64‑bit cores at 1.6 GHz providing a modern, energy‑efficient CPU complex for embedded workloads.
• Memory Integrated controllers for DDR3L and DDR4 memory to support a range of board‑level memory options and performance profiles.
• Networking & SerDes Flexible Ethernet configurations (1GbE (7) or 10GbE (1) & 1GbE (5) as specified) and a four‑lane, 10 GHz multi‑protocol SerDes for high‑speed interface support; integrated Frame Manager provides packet parsing and classification.
• PCIe, Storage & USB Support for multiple DMA‑controlled PCIe Gen2 interfaces (as described in the series datasheet), one SATA 6 Gbps port and two USB 3.0 ports with PHY for high‑speed storage and peripheral connectivity.
• Security On‑chip security features including Secure Boot and ARM® TrustZone® to enable trusted system boot and hardware‑enforced isolation.
• Integration & Offload QorIQ data path acceleration architecture and integrated frame processing engines reduce CPU overhead for packet processing and inline security operations.
• Package & Mounting 621‑FCPBGA (21 × 21 mm) surface mount package suitable for compact, system‑level designs.
• Industrial Qualification & Temperature Range Industrial qualification with operating temperature range from ‑40°C to 105°C for deployment in demanding environments.

Typical Applications

• Branch Office and Edge Routers Provides multi‑port Ethernet, hardware packet processing and security features suitable for compact routing and edge NAT/firewall functions.
• vCPE and Edge Equipment Dual‑core 64‑bit processing plus DPAA offloads enable virtualized customer premises equipment and edge network functions with reduced CPU load.
• Multi‑Protocol IoT Gateways Flexible I/O, SerDes and security features help build gateways that aggregate and secure large numbers of IoT endpoints.
• Industrial PLC and Control Industrial qualification and wide operating temperature range make the device suitable for control applications in harsh environments.
• Security Appliances Integrated security engine, Secure Boot and TrustZone® support inline IPsec and other cryptographic offloads for secure networking appliances.

Unique Advantages

• Highly integrated I/O: Multiple Ethernet configurations, SATA 6 Gbps and USB 3.0 reduce external silicon and simplify system BOM.
• Security built in: Secure Boot and TrustZone® enable hardware‑rooted trust and partitioning for secure system designs.
• Industrial ready: Industrial qualification and a −40°C to 105°C operating range support deployment in temperature‑challenging environments.
• Small form factor package: The 621‑FCPBGA (21×21 mm) package supports compact board layouts for space‑constrained designs.
• Optimized packet processing: Integrated Frame Manager and DPAA offloads lower CPU overhead for networking workloads, enabling greater throughput without adding CPU cores.
• Flexible memory support: DDR3L and DDR4 controller support allows designers to tailor memory selection for cost or performance targets.

Why Choose LS1023AXE7QQB?

The LS1023AXE7QQB positions itself as a balanced, embedded networking and industrial microprocessor: a modern 64‑bit dual‑core ARM® Cortex®‑A53 CPU paired with extensive I/O, onboard security, and packet‑processing acceleration. It is well suited for compact routers, edge appliances, IoT gateways and industrial control systems that need both performance and system integration.

Designers benefit from a reduced BOM and simplified board design thanks to integrated SerDes, multi‑port Ethernet options, storage and USB interfaces, together with industrial qualification for long‑life deployments. The combination of TrustZone®, Secure Boot and dedicated offload engines helps protect data and sustain throughput in demanding networked applications.
