MC68EC000EI16R2

The MC68EC000EI16R2 is a single-core 32-bit microprocessor from the MC68EC000 series, manufactured by NXP Semiconductors. It operates at 16 MHz with 5 V I/O and is supplied in a 68-pin PLCC surface-mount package.

Designed for embedded, consumer-focused applications, this device offers straightforward integration into systems that require a classic M68000-family instruction set and documented programming model as provided in the family reference materials.

Key Features

• Core & Performance EC000 core processor with a single 32-bit core running at 16 MHz, providing deterministic processing for embedded control and application logic.
• Power 5 V I/O voltage, enabling compatibility with legacy 5 V system interfaces.
• Package & Mounting 68-LCC (J-Lead) / 68-PLCC (24.21 × 24.21 mm) supplier package in a surface-mount form factor for board-level integration.
• Operating Environment Qualified for consumer applications with an operating temperature range of 0 °C to 70 °C.
• Standards & Compliance RoHS compliant, supporting regulatory requirements for lead-free assemblies.
• Documentation Part of the M68000 family with a published Programmer’s Reference Manual covering the CPU32 instruction set and programming models for registers and floating-point architecture at the family level.
• Graphics & Acceleration No integrated graphics acceleration—focused on CPU processing for embedded control tasks.

Typical Applications

• Embedded Systems — Integration in embedded consumer equipment where a 32-bit M680x0-class CPU and 5 V I/O are required for control and processing tasks.
• Consumer Electronics — Use in consumer-grade products that operate within a 0 °C to 70 °C range and require RoHS-compliant components.
• Legacy M68000-Based Designs — Suitable for designs relying on M68000-family architecture and documented programming models for maintenance or replacement parts.

Unique Advantages

• Established M68000 Family Documentation: The product is supported by the M68000 Programmer’s Reference Manual, providing detailed CPU32 instruction and programming-model information useful for development and maintenance.
• 32-Bit Single-Core Architecture: A straightforward single 32-bit core design at 16 MHz that simplifies software porting and deterministic embedded control.
• 5 V I/O Compatibility: Native 5 V I/O simplifies integration with existing 5 V system buses and peripherals.
• Surface-Mount PLCC Package: 68-PLCC (24.21 × 24.21 mm) J-lead package enables compact board-level mounting and straightforward replacement in PLCC footprints.
• RoHS Compliant: Meets lead-free assembly requirements for consumer hardware production.
• Consumer Temperature Qualification: Rated for 0 °C to 70 °C operation, matching typical consumer product environmental requirements.

Why Choose MC68EC000EI16R2?

The MC68EC000EI16R2 provides a concise, documented implementation of the M680x0-class architecture in a single 32-bit core at 16 MHz, packaged for surface-mount PLCC deployment. Its 5 V I/O, consumer temperature rating, and RoHS compliance make it suitable for embedded consumer applications and systems maintaining M68000-family architectures.

Backed by NXP Semiconductors and supported by the M68000 family reference documentation, this part is appropriate for engineers seeking a documented, legacy-compatible microprocessor solution with clear electrical and mechanical specifications.
