MC68EC000EI20R

The MC68EC000EI20R from NXP Semiconductors is a single-core, 32-bit EC000 microprocessor running at 20 MHz in a 68-pin PLCC surface-mount package. It is offered for embedded, consumer-grade applications that require a 32-bit processing core with 5 V I/O and a commercial operating temperature range.

This device combines the EC000 core architecture with a compact 68-PLCC footprint (24.21×24.21) and RoHS compliance, making it suitable for consumer embedded designs that rely on a standard surface-mount microprocessor form factor.

Key Features

• Core EC000 core processor; single 32-bit processing core suitable for embedded control and application processing.
• Clock Speed 20 MHz operating frequency for deterministic, low‑to‑moderate throughput embedded tasks.
• Voltage I/O 5 V I/O signaling compatible with 5 V logic systems.
• Package & Mounting 68‑PLCC supplier device package (24.21×24.21) in a 68‑LCC (J‑Lead) case, designed for surface mount assembly.
• Qualification & Temperature Consumer qualification with an operating temperature range of 0 °C to 70 °C for commercial applications.
• Graphics No integrated graphics acceleration.
• Compliance RoHS compliant.
• Documentation Family programmer’s reference documentation is available for the M68000 family, covering the integer unit programming model, floating‑point unit user programming model, supervisor programming model, and data formats.

Typical Applications

• Consumer Embedded Systems — Use as the main processing element in consumer electronics requiring a single 32‑bit core and standard 5 V I/O.
• Interface and Control — Suitable for control and peripheral interfacing tasks in embedded designs where a 20 MHz 32‑bit core meets performance needs.
• Surface‑Mount PCB Designs — Ideal for boards designed around a 68‑PLCC package (24.21×24.21) and J‑lead mounting.

Unique Advantages

• 32‑Bit Processing: Single EC000 32‑bit core provides straightforward 32‑bit computation for embedded applications.
• Standard 5 V I/O: Direct compatibility with 5 V logic simplifies integration into established system designs.
• Compact PLCC Footprint: 68‑PLCC (24.21×24.21) package enables a compact surface‑mount solution with established board‑level support.
• Commercial Temperature Range: Rated for 0 °C to 70 °C to meet typical consumer product environment requirements.
• Regulatory Compliance: RoHS compliance supports environmentally driven design requirements.
• Family Documentation: Detailed M68000 family programmer’s reference material is available to support software and system development.

Why Choose MC68EC000EI20R?

The MC68EC000EI20R positions itself as a practical 32‑bit microprocessor choice for consumer embedded designs that require a single EC000 core running at 20 MHz with 5 V I/O. Its 68‑PLCC surface‑mount package and RoHS compliance make it straightforward to integrate into existing board layouts and manufacturing flows.

This part is well suited to designers seeking a commercially qualified 32‑bit MCU option backed by M68000 family programmer’s reference documentation to assist software development and system integration.

Request a quote or submit an RFQ to obtain pricing, availability, and delivery lead times for the MC68EC000EI20R.
