MPC7410THX400LE

The MPC7410THX400LE is a PowerPC G4 RISC microprocessor implementing the full 32‑bit PowerPC architecture and delivered in a 360‑CBGA (25×25) surface‑mount package. Targeted at computing and embedded systems applications, the device combines a 400 MHz core with architectural features aimed at improved memory bandwidth and multiprocessing support.

With industrial qualification and an operating temperature range of −40 °C to 105 °C, this part is suited for designs that require a robust, single‑core 32‑bit processor in a compact BGA package.

Key Features

• Core PowerPC G4 32‑bit single core running at 400 MHz, providing a standardized RISC instruction set implementation.
• AltiVec Technology Implementation includes the AltiVec instruction set as described in series documentation, enabling vector processing capabilities where supported by software.
• Memory and Cache Improved memory subsystem (MSS) bandwidth with configurable direct‑mapped SRAM capability on the L2 cache interface and support for a 32‑bit L2 cache interface.
• Multiprocessing & Coherency Hardware‑based multiprocessing capability with a five‑state cache coherency protocol (four MESI states plus a shared intervention state) to support coherent multi‑processor systems.
• Bus Interfaces Optional high‑bandwidth MPX bus interface and enhancements to bus/addressing provided in the MPC7410 series documentation.
• Performance & Pipeline Four instructions fetched per clock and a branch processing unit capable of processing one branch per cycle; architecture retains a four‑stage pipeline model (fetch, decode/dispatch, execute, complete/writeback).
• Package & Mounting 360‑CBGA (25×25) BGA package, surface mount, supplier device package listed as 360‑CBGA (25×25).
• Environmental & Qualification Industrial qualification with an operating temperature range of −40 °C to 105 °C and RoHS compliance.
• Graphics No dedicated graphics acceleration.

Typical Applications

• Embedded Systems Single‑core 32‑bit processing for control, data handling, and protocol tasks in embedded applications that benefit from PowerPC architecture.
• Industrial Control & Automation Industrial qualification and wide operating temperature range make the part suitable for controllers and instrumentation operating in harsh environments.
• Multiprocessor Systems Designed for systems requiring hardware multiprocessing and coherent cache behavior for multi‑CPU configurations.
• Networking & Telecom Appliances Improved memory subsystem bandwidth and bus interface options are applicable where packet processing and sustained data throughput are required.

Unique Advantages

• Vector Processing Support: Inclusion of the AltiVec instruction set enables vectorized workloads where applicable, improving data‑parallel performance when used by software.
• Enhanced Memory Bandwidth: Memory subsystem improvements and configurable L2 features help sustain higher data throughput for memory‑intensive tasks.
• Hardware Multiprocessing: Built‑in multiprocessing capability with a five‑state coherency protocol simplifies design of coherent multi‑CPU systems.
• Industrial Ready: Industrial qualification and −40 °C to 105 °C operating range support deployment in demanding environments.
• Compact BGA Packaging: 360‑CBGA (25×25) surface‑mount package provides a high‑density solution for space‑constrained PCB designs.
• Standards‑Based Architecture: Full PowerPC 32‑bit architecture implementation facilitates integration into existing PowerPC‑based software ecosystems and toolchains.

Why Choose MPC7410THX400LE?

The MPC7410THX400LE positions itself as a robust single‑core PowerPC G4 solution for embedded and computing applications that require a 400 MHz 32‑bit processor with enhanced memory subsystem features and hardware multiprocessing capability. Its industrial qualification and wide operating temperature range make it appropriate for designs that demand reliability across harsh environments.

Backed by detailed series documentation from the manufacturer, the part is suitable for engineers seeking a compact BGA package, coherent multiprocessing support, and AltiVec vector capabilities where applicable to software workloads.

Request a quote or submit your requirements to receive pricing and availability information for the MPC7410THX400LE.
