TMUX8109RUMR
100-V, FLAT RON, DUAL 4:1 MULTIP
| Part Description |
2 Circuit IC Switch 4:1 48Ohm 16-WQFN (4x4) |
|---|---|
| Quantity | 328 Available (as of May 6, 2026) |
| Product Category | Analog Switches, Multiplexers, Demultiplexers |
|---|---|
| Manufacturer | Texas Instruments |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 12 Weeks |
| Datasheet |
Specifications
| Part Package | 16-WQFN Exposed Pad |
|---|---|
| Device Package | 16-WQFN (4×4) |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Switch Circuit: | SP4T – NO |
| Multiplexer/Demultiplexer Circuit: | 4:1 |
| Number of Circuits: | 2 |
| On-State Resistance (Max): | 48Ohm |
| Channel-to-Channel Matching (ΔRon): | 650mOhm |
| Voltage – Supply, Single (V+): | 10V ~ 100V |
| Voltage – Supply, Dual (V±): | ±10V ~ 50V |
| Switch Time (Ton, Toff) (Max): | 15µs, 3µs |
| -3db Bandwidth: | 380MHz |
| Charge Injection: | -150pC |
| Channel Capacitance (CS(off), CD(off)): | 3pF, 10pF |
| Current – Leakage (IS(off)) (Max): | 15nA |
| Crosstalk: | -110dB @ 1MHz |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | ROHS3 Compliant |
| Moisture Sensitivity Level | 2 (1 Year) |
| ECCN | N/A |
| HTS Code | N/A |
