TMUX8212RUMR
100-V, FLAT RON, 1:1 (SPST), FOU
| Part Description |
4 Circuit IC Switch 1:1 7Ohm 16-WQFN (4x4) |
|---|---|
| Quantity | 1,338 Available (as of May 6, 2026) |
| Product Category | Analog Switches, Multiplexers, Demultiplexers |
|---|---|
| Manufacturer | Texas Instruments |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 12 Weeks |
| Datasheet |
Specifications
| Part Package | 16-WQFN Exposed Pad |
|---|---|
| Device Package | 16-WQFN (4×4) |
| Mounting Method | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Switch Circuit: | SPST – NO |
| Multiplexer/Demultiplexer Circuit: | 1:1 |
| Number of Circuits: | 4 |
| On-State Resistance (Max): | 7Ohm |
| Channel-to-Channel Matching (ΔRon): | 200mOhm |
| Voltage – Supply, Single (V+): | 10V ~ 100V |
| Voltage – Supply, Dual (V±): | ±10V ~ 50V |
| Switch Time (Ton, Toff) (Max): | 4µs, 100ns (Typ) |
| -3db Bandwidth: | 420MHz |
| Charge Injection: | -1.3nC |
| Channel Capacitance (CS(off), CD(off)): | 12pF, 12pF |
| Current – Leakage (IS(off)) (Max): | 10pA (Typ) |
| Crosstalk: | -100dB @ 100kHz |
Environmental
| REACH Compliance | REACH Unaffected |
|---|---|
| RoHS Compliance | ROHS3 Compliant |
| Moisture Sensitivity Level | 2 (1 Year) |
| ECCN | EAR99 |
| HTS Code | 8542.39.0001 |
