A42MX24-WAFERLOT

The A42MX24-WAFERLOT is an MX field programmable gate array (FPGA) supplied as a die, manufactured by Microchip Technology. It provides a compact, automotive‑grade programmable logic solution with 912 logic elements and an estimated 36,000 gates for implementing custom digital functions.

Qualified to AEC‑Q100 and RoHS compliant, this die‑form FPGA accepts a wide voltage supply range of 3 V to 5.5 V, making it appropriate for designs that require automotive qualification and flexible power-domain integration.

Key Features

• Logic Resources  912 logic elements and approximately 36,000 gates for implementing custom combinational and sequential logic.
• Memory  No embedded RAM (0 bits), providing a predictable resource set focused on logic element utilization.
• Supply Range  Operates from 3 V to 5.5 V, allowing use across multiple power domains within vehicle and industrial systems.
• Automotive Qualification  AEC‑Q100 qualification and an automotive grade designation for applications requiring recognized automotive component qualification.
• Package and Mounting  Supplied in die form with surface mount mounting type for space‑efficient integration into custom board assemblies or multi‑chip modules.
• Environmental Compliance  RoHS compliant for restricted‑substance conformance in regulated markets.
• Manufacturer  Produced by Microchip Technology, providing component traceability and manufacturing provenance.

Typical Applications

• Automotive Subsystems  Use as programmable logic in automotive electronics where AEC‑Q100 qualification is required for component selection.
• Custom Control Logic  Implement application‑specific logic functions and glue logic when a compact die‑form FPGA is needed for tight board space.
• Hardware Prototyping for Qualified Designs  Evaluate and validate logic architectures intended for automotive‑qualified production implementations.

Unique Advantages

• Automotive‑qualified Programmability:  AEC‑Q100 qualification provides a clear path for integration into automotive systems that require qualified components.
• Compact Die Form:  Die‑package delivery enables high‑density board implementations and custom packaging or module integration.
• Wide Supply Voltage:  3 V to 5.5 V operation simplifies interfacing to a range of vehicle and industrial power rails.
• Deterministic Logic Resources:  A fixed set of 912 logic elements and no embedded RAM gives predictable resource planning for logic‑centric designs.
• Regulatory Compliance:  RoHS compliance supports environmental and materials requirements for many global programs.

Why Choose A42MX24-WAFERLOT?

The A42MX24-WAFERLOT offers a focused, automotive‑grade FPGA option for designs that require qualified programmable logic in a compact die form. With 912 logic elements, an approximate 36,000‑gate capacity, and AEC‑Q100 qualification, it is positioned for engineers integrating programmable logic into vehicle electronics or other applications where component qualification and a controlled resource set matter.

Its broad 3 V to 5.5 V supply range and RoHS compliance further simplify system integration and regulatory planning, delivering a reliable, traceable FPGA die from Microchip Technology for production programs that demand qualification and predictable logic resources.

Request a quote or submit an inquiry to receive pricing, availability, and additional ordering information for the A42MX24-WAFERLOT.
