A42MX36-2BG272

The A42MX36-2BG272 is an MX Field Programmable Gate Array (FPGA) from Microchip Technology. It provides a balanced resource set including 1,184 logic elements (cells), 54,000 gates and 202 user I/O pins in a compact 272-ball BBGA/PBGA package.

Designed for commercial-grade applications, the device supports a voltage supply range of 3 V to 5.25 V, operates over a 0 °C to 70 °C temperature range, and is supplied in a surface-mount 272-BBGA (supplier package: 272-PBGA, 27×27) package. The part is RoHS compliant.

Key Features

• Core resources  1,184 logic elements (cells) and 54,000 gates provide the programmable fabric for implementing custom logic and control functions.
• On-chip memory  2,560 total RAM bits of embedded memory for small data buffering and state storage.
• I/O capacity  202 user I/O pins to support a wide range of peripheral connections and bus interfaces.
• Package & mounting  Surface-mount 272-BBGA package (supplier device package: 272-PBGA, 27×27) for compact board-level integration.
• Power  Operates from a 3 V to 5.25 V supply range to match common logic and legacy power rails.
• Temperature & grade  Commercial-grade device rated for operation from 0 °C to 70 °C.
• Environmental compliance  RoHS compliant for regulatory and assembly requirements.

Unique Advantages

• Balanced logic density: The combination of 1,184 logic elements and 54,000 gates delivers moderate programmable capacity for control and glue-logic functions without excessive board area.
• Generous I/O count: With 202 I/O pins, the device supports multiple peripheral interfaces and parallel connections directly on-chip.
• Compact PBGA footprint: The 272-BBGA / 272-PBGA (27×27) package offers a small board footprint for space-constrained designs while maintaining high I/O density.
• Flexible supply range: Support for 3 V to 5.25 V operation allows integration with a range of logic families and legacy power systems.
• Commercial availability: Commercial-grade temperature range and surface-mount packaging simplify qualification for standard electronics and embedded applications.
• RoHS compliant: Conforms to environmental requirements for modern electronics manufacturing and assembly.

Why Choose A42MX36-2BG272?

The A42MX36-2BG272 is suited to designers seeking a commercially graded FPGA with a moderate mix of logic, memory and I/O capacity in a compact PBGA package. Its combination of 1,184 logic elements, 54,000 gates and 202 I/Os makes it a practical choice for control, interface, and mid-density programmable functions where board space and I/O count are important.

With a wide supply voltage range, surface-mount 272-BBGA package and RoHS compliance, this Microchip FPGA offers predictable integration into commercial electronic designs while providing the programmable flexibility to iterate hardware functionality without large BOM changes.
