A42MX36-BG272

The A42MX36-BG272 is a Microchip Technology MX series field programmable gate array (FPGA) provided in a 272-BBGA surface-mount package. It offers a moderate logic and memory resource set including 1,184 logic elements, approximately 2,560 bits of on‑chip RAM and 54,000 gates, with 202 user I/O pins for system integration.

Packaged in a 272‑PBGA (27×27) footprint and rated for commercial use, the device operates from a 3 V to 5.25 V supply and is specified for an ambient range of 0 °C to 70 °C, making it suitable for a wide range of standard electronic designs that require reprogrammable logic capacity in a compact BGA form factor.

Key Features

• Logic Capacity  Provides 1,184 logic elements and 54,000 gates to implement combinational and sequential logic functions at the board level.
• Embedded Memory  Approximately 2,560 bits of on‑chip RAM allow local storage for small buffers, state machines and register files.
• I/O Density  202 general-purpose I/O pins support interfacing to multiple peripherals and board-level signals without external I/O expanders.
• Package & Mounting  Delivered in a 272‑BBGA package (supplier device package 272‑PBGA 27×27) for surface-mount assembly, enabling a compact PCB footprint.
• Power Supply Range  Operates from 3 V to 5.25 V supply rails to match common logic and legacy voltage domains.
• Commercial Grade Temperature  Specified for 0 °C to 70 °C operation for standard commercial applications.
• Manufacturer & Family  Part of Microchip Technology’s MX FPGA family, supporting integration into MX‑based designs.
• RoHS Compliant  Manufactured to meet RoHS environmental requirements.

Typical Applications

• Board-level glue logic  Use the device to consolidate discrete logic and implement custom interfacing functions with up to 202 I/O pins.
• Control and state machines  1,184 logic elements and embedded RAM support finite-state controllers and small control frameworks.
• Prototyping and development  Reprogrammable logic capacity in a compact BGA package enables iterative hardware development and proof-of-concept designs.

Unique Advantages

• Balanced resource set: Combines a measurable logic element count with embedded RAM and a high I/O count for flexible implementation of mid‑scale logic designs.
• Compact BGA footprint: 272‑BBGA (272‑PBGA 27×27) packaging reduces PCB area while providing high I/O density for space‑constrained systems.
• Wide supply compatibility: Support for 3 V to 5.25 V supplies enables interfacing with a range of legacy and modern voltage domains without external level shifting in many cases.
• Commercial temperature rating: Specified 0 °C to 70 °C operation aligns with standard commercial electronics deployment and procurement cycles.
• RoHS compliance: Environmentally compliant manufacturing supports regulatory and assembly requirements.

Why Choose A42MX36-BG272?

The A42MX36-BG272 positions itself as a compact, reprogrammable logic device for designs that need moderate logic capacity, embedded memory, and significant I/O in a surface‑mount BGA package. Its combination of 1,184 logic elements, approximately 2,560 bits of RAM and 202 I/O pins provides designers with the resources to consolidate logic and implement custom interfacing while maintaining a small PCB footprint.

Suited for commercial‑grade applications and backed by Microchip’s MX FPGA family documentation, this device offers a practical balance of performance, integration and manufacturability for teams developing board‑level digital logic, control systems and prototype implementations.

Request a quote or submit an inquiry to purchase A42MX36-BG272 and get specific pricing and availability information for your project.
