AGLN250V2-CSG81

The AGLN250V2-CSG81 is an IGLOO nano Field Programmable Gate Array (FPGA) IC from Microchip Technology. It integrates 6,144 logic elements and approximately 36,864 bits of on-chip RAM in a compact 81-WFBGA CSBGA package.

With 60 user I/O, an estimated 250,000 gates of logic capacity, and a supply voltage range of 1.14 V to 1.575 V, this commercial-grade, surface-mount FPGA is designed for compact designs that require programmable logic and embedded memory within a standard commercial temperature range.

Key Features

• Core Logic 6,144 logic elements (cells) providing a mid-density programmable fabric for custom logic and control functions.
• Embedded Memory Approximately 0.037 Mbits (36,864 bits) of on-chip RAM for buffering, small lookup tables, and state storage.
• I/O Resources 60 user I/O pins to support a range of peripheral and interface connections on a single FPGA device.
• Gate Capacity Approximately 250,000 gates of logic capacity for implementing combinational and sequential designs.
• Power Operates from a supply voltage range of 1.14 V to 1.575 V to match system power rails and design constraints.
• Package and Mounting 81-WFBGA, CSBGA package (supplier device package: 81-CSP 5×5) in a surface-mount form factor for compact PCB integration.
• Temperature Grade Commercial operating temperature range of −20°C to 85°C for standard commercial applications.
• Compliance RoHS compliant to meet common lead-free manufacturing requirements.

Typical Applications

• Consumer and Embedded Electronics Compact programmable logic and I/O interfacing where 6,144 logic elements and 60 I/Os enable integration of custom peripherals and glue logic.
• Control and Signal Processing Small-scale control, pre-processing, and protocol handling using on-chip RAM and the device’s gate capacity for custom state machines and buffering.
• Prototyping and Custom Logic Development and validation of custom logic functions in a commercial-temperature FPGA package suitable for board-level evaluation and integration.

Unique Advantages

• Mid-density programmable fabric: 6,144 logic elements provide a balance of capacity and package size for many custom logic tasks without overprovisioning.
• Integrated embedded memory: 36,864 bits of on-chip RAM reduce external memory requirements for small buffers and lookup tables.
• Compact CSP/WFBGA packaging: 81-WFBGA (81-CSP 5×5) surface-mount package saves PCB area and supports high-density board layouts.
• Flexible I/O count: 60 user I/Os enable multiple peripheral connections and interface combinations on a single device.
• Commercial temperature and RoHS compliance: Suitable for standard commercial deployments with lead-free manufacturing compliance.
• Defined supply range: 1.14 V to 1.575 V operation to match modern supply architectures in compact systems.

Why Choose AGLN250V2-CSG81?

The AGLN250V2-CSG81 delivers a compact, mid-density FPGA option for designers who need a programmable solution with 6,144 logic elements, on-chip RAM, and 60 I/Os in a small 81-WFBGA CSBGA package. Its defined supply voltage range and commercial operating temperature make it suitable for a wide range of standard embedded and consumer-focused designs.

Manufactured by Microchip Technology and RoHS compliant, this device is a practical choice for projects that require integrated logic and memory in a surface-mount form factor while maintaining a clear set of electrical and thermal operating parameters.

Request a quote or submit a sourcing inquiry to learn about availability and lead times for the AGLN250V2-CSG81.
