XC4013XL-1HT176C

The XC4013XL-1HT176C is a commercial-grade FPGA from AMD's XC4000E/X family, supplied in a 176-LQFP exposed pad package. It delivers medium-density programmable logic suitable for commercial applications that require a balance of logic capacity, on-chip memory, and a generous number of I/O pins.

Key device characteristics include 1,368 logic elements, approximately 18,432 bits of embedded RAM, up to 145 user I/O pins, and an operating voltage range of 3.0 V to 3.6 V, making it a practical choice for designs constrained by board space and standard commercial temperature profiles.

Key Features

• Core Logic 1,368 logic elements provide medium-density programmable logic resources for implementing custom digital functions.
• Embedded Memory Approximately 18,432 bits of on-chip RAM to support local buffering, state storage, and small lookup tables.
• I/O Capacity Up to 145 user I/O pins to accommodate multiple external interfaces and peripheral connections.
• Gate Equivalence Equivalent to approximately 13,000 gates for estimating legacy gate-count requirements.
• Power Operates from a 3.0 V to 3.6 V supply range, compatible with common commercial power rails.
• Package & Mounting Supplied in a 176-LQFP exposed pad package (supplier package listed as 176-TQFP, 24 × 24), designed for surface-mount assembly.
• Operating Range Commercial temperature grade with an operating temperature range of 0 °C to 85 °C.
• Compliance RoHS compliant for environmentally conscious assembly and supply-chain requirements.

Typical Applications

• Commercial control and interface designs — Use the device’s 145 I/O pins and 1,368 logic elements to implement sensor interfacing, protocol translation, and control logic in commercial systems.
• Glue logic and peripheral aggregation — Replace multiple discrete components by consolidating glue logic and peripheral interfaces within the FPGA’s programmable fabric and embedded memory.
• Prototyping and evaluation — Medium-density resources and standard 176-LQFP packaging support board-level development and evaluation for commercial product concepts.

Unique Advantages

• Right-sized capacity: 1,368 logic elements and ~18,432 bits of RAM provide a balance between functionality and cost for medium-complexity designs.
• Generous I/O: 145 available I/O pins allow consolidation of multiple external interfaces without immediate need for additional I/O expanders.
• Standard packaging: 176-LQFP exposed pad in a 24 × 24 footprint supports surface-mount assembly and heat dissipation considerations for commercial PCBs.
• Commercial temperature design: Rated 0 °C to 85 °C to match typical commercial application environments.
• RoHS compliant: Meets common environmental requirements for modern electronic assembly.

Why Choose XC4013XL-1HT176C?

The XC4013XL-1HT176C positions itself as a medium-density, commercial-grade FPGA that combines a practical count of logic elements, embedded RAM, and extensive I/O in a compact surface-mount package. It is well suited to designers who need to implement custom digital logic, consolidate peripheral interfaces, or evaluate commercial product concepts without stepping up to larger-capacity devices.

Manufactured by AMD and supplied in a 176-LQFP exposed pad package, this device offers predictable electrical and thermal characteristics for commercial boards powered from a 3.0–3.6 V supply and operating within standard commercial temperature limits.

Request a quote or submit a purchase inquiry to receive pricing and availability for the XC4013XL-1HT176C. Include quantity and required delivery timeframe to expedite response.
