XCS10XL-5TQ144C

The XCS10XL-5TQ144C is a Spartan®-XL field-programmable gate array (FPGA) from AMD designed for commercial electronic applications requiring compact, reconfigurable logic. It features 466 logic elements, 112 user I/O pins and on-chip RAM to implement glue logic, interface bridging and control functions in a surface-mount 144-LQFP package.

With a 3.0 V to 3.6 V supply range, RoHS compliance and an operating temperature range of 0°C to 85°C, this FPGA targets commercial embedded systems where moderate logic density and flexible I/O are required.

Key Features

• Core Logic  466 logic elements (cells) provide the programmable resources for implementing custom combinational and sequential logic functions.
• On-chip Memory  6,272 bits of embedded RAM available for small buffers, state storage and control data.
• I/O Capacity  112 user I/O pins support interfacing with peripherals, sensors and external logic devices.
• Gate Equivalent  Approximately 10,000 gates of logic capacity for compact system designs.
• Power  Operates from a 3.0 V to 3.6 V supply, suitable for common commercial voltage rails.
• Package & Mounting  Surface-mount 144-LQFP package (supplier device package: 144-TQFP 20×20) for PCB space-efficient assembly.
• Commercial Temperature Grade  Rated for 0°C to 85°C operation to meet typical commercial environment requirements.
• Compliance  RoHS compliant, meeting lead-free manufacturing requirements.

Typical Applications

• Embedded Control  Implement custom control logic, finite-state machines and small peripheral managers using the device's programmable logic and on-chip RAM.
• Interface Bridging  Use the 112 I/O pins to translate, aggregate or buffer signals between subsystems and external devices.
• Prototyping & Development  Compact FPGA resource set makes this part suitable for proof-of-concept designs and early-stage hardware validation.
• Consumer & Commercial Electronics  Integrate custom logic functions in commercial-grade products where moderate logic density and standard temperature ratings are acceptable.

Unique Advantages

• Right-sized Logic Capacity:  466 logic elements and roughly 10,000 gates deliver sufficient programmable resources for glue logic and control tasks without excessive area or power overhead.
• Balanced I/O Count:  112 I/O pins provide flexible connectivity for multi-peripheral designs and board-level integration.
• On-chip Memory for Control:  6,272 bits of embedded RAM support buffering and small data storage needs directly in the FPGA fabric.
• Standard Supply Voltage:  3.0 V to 3.6 V operation aligns with common commercial power rails, simplifying power supply design.
• Compact Surface-Mount Package:  144-LQFP (144-TQFP 20×20) enables dense PCB layout and automated assembly processes.
• Commercial Grade & RoHS Compliant:  Rated for 0°C to 85°C operation and lead-free manufacturing compliance for mainstream product lines.

Why Choose XCS10XL-5TQ144C?

The XCS10XL-5TQ144C positions itself as a practical, commercial-grade FPGA option for designers who need moderate programmable logic, ample I/O and on-chip RAM in a compact surface-mount package. Its combination of 466 logic elements, 112 I/O pins and 6,272 bits of embedded memory makes it well suited to implement glue logic, protocol adaptors and control functions in space-constrained designs.

Manufactured by AMD and available in a 144-LQFP package, this part offers a balance of integration, verifiable electrical characteristics and RoHS compliance for commercial products, prototypes and short-run production where those attributes matter.

If you would like pricing or availability for XCS10XL-5TQ144C, request a quote or submit an inquiry and our team will respond with the next steps.
