MC68EC040FE40A
| Part Description |
68040 Microprocessor IC M680x0 1 Core, 32-Bit 40MHz 184-CQFP (31.3x31.3) |
|---|---|
| Quantity | 434 Available (as of October 8, 2026) |
| Product Category | Microprocessors |
|---|---|
| Part Series | MC68EC040 |
| Manufacturer | NXP USA Inc. |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | Contact Us |
| Datasheet |
Specifications & Environmental
| Core Processor | 68040 | Device Package | 184-CQFP (31.3x31.3) | ECCN | 3A991A2 | ||
|---|---|---|---|---|---|---|---|
| Graphics Acceleration | No | HTS Code | 8542.31.0001 | Moisture Sensitivity Level | 1 (Unlimited) | ||
| Mounting Method | Surface Mount | Mounting Type | Surface Mount | Number of Cores/Bus Width | 1 Core, 32-Bit | ||
| Operating Temperature | 0°C ~ 70°C (TA) | Package / Case | 184-BCQFP | REACH Compliance | REACH Unaffected | ||
| RoHS Compliance | ROHS3 Compliant | Speed | 40MHz | Supplier Device Package | 184-CQFP (31.3×31.3) | ||
| Voltage – I/O | 5.0V |
Overview of MC68EC040FE40A – IC MPU M680X0 40MHZ 184CQFP
The MC68EC040FE40A is a 68040-series microprocessor from NXP Semiconductors. It implements a single 32-bit 68040 core running at 40 MHz in a surface-mount 184-CQFP package (31.3 × 31.3 mm), and is offered for embedded system applications.
Documentation for the M68040 family describes the architecture and programming model for the 32-bit third‑generation M68040 microprocessors; derivative differences within the family are identified in the series user manual.
Key Features
- Core & Architecture Single 68040 core, 32-bit architecture as specified for the M68040 family.
- Clock Speed 40 MHz operating frequency for the processor core.
- Voltage 5 V I/O voltage for integration with 5 V system logic.
- Package & Mounting 184-CQFP surface-mount package, dimensions 31.3 × 31.3 mm, suitable for PCB-mounted embedded designs.
- Interfaces Includes SCI (Serial Communication Interface) for serial peripheral connectivity.
- Operating Range & Compliance Commercial temperature range of 0 °C to 70 °C and RoHS compliant.
Unique Advantages
- 68040 architecture: Provides a standardized 32-bit single-core MPU architecture for designs targeting the M68040 family.
- Compact surface-mount package: 184-CQFP (31.3 × 31.3 mm) offers a defined footprint for board-level integration in embedded assemblies.
- Established documentation: The M68040 family user manual documents capabilities and programming details for designers referencing the series.
- 5 V I/O compatibility: Simplifies integration with legacy 5 V system logic and peripherals.
- Regulatory readiness: RoHS compliance supports modern manufacturing and environmental requirements.
Why Choose MC68EC040FE40A?
The MC68EC040FE40A positions the M68040 family’s 32-bit single-core architecture in a 40 MHz, surface-mount form factor that is appropriate for embedded system implementations requiring a defined package and electrical interface. With clear manufacturer documentation and a standardized 184-CQFP footprint, this part supports designs that depend on the M68040 family architecture and 5 V I/O compatibility.
Request a quote or submit a pricing inquiry for MC68EC040FE40A to confirm availability, lead times, and quantity pricing for your project requirements.
