MC68EC030FE25C

The MC68EC030FE25C is a 32‑bit embedded controller based on the 68030 core, delivering a single 32‑bit processing core at 25 MHz in a 132‑CQFP (24×24) surface‑mount package. It is designed for embedded control applications that require a compact, code‑compatible M680x0 architecture with integrated cache and flexible bus interfacing.

Key value comes from integrated instruction and data caches, a burst‑mode bus interface with dynamic bus sizing, and support for standard coprocessor connectivity—enabling efficient memory system use and straightforward migration for designs leveraging the M68000 family.

Key Features

• Core & Architecture 68030 core processor providing a single 32‑bit execution core running at 25 MHz, preserving the M68000 family instruction set and addressing modes.
• On‑Chip Caches Integrated on‑chip data cache (256 bytes) and instruction cache (256 bytes) to reduce external memory accesses and improve execution efficiency.
• Burst‑Mode Bus Interface Burst‑mode bus transfers and an enhanced bus controller support efficient DRAM access and overlapped instruction execution for improved throughput.
• Flexible Memory Interface Dynamic bus sizing enables direct interfacing to 8‑, 16‑, and 32‑bit devices; the device also provides complete 32‑bit nonmultiplexed address and data buses and a 4‑Gbyte direct addressing range.
• System Integration & Control Two access control registers allow blocks to be defined for cacheability protection; full coprocessor interface support simplifies integration of external coprocessors.
• Packaging & Power Supplied in a 132‑CQFP (24×24) surface‑mount package with Vio specified at 5 V and an operating temperature range of 0 °C to 70 °C.
• Interfaces Includes SCI as an additional interface for serial communications and peripheral integration.
• Compliance RoHS status: Compliant.

Typical Applications

• Embedded Control Systems Use as the main controller in embedded control applications where M680x0 code compatibility and integrated caches improve system responsiveness.
• Industrial Automation Suitable for automation controllers and process control modules that benefit from the device’s burst‑mode bus interface and dynamic bus sizing when interfacing to varied memory and I/O widths.
• Communications & Interface Modules With SCI and nonmultiplexed address/data buses, the device fits communication interface designs requiring deterministic bus behavior and legacy M680x0 compatibility.

Unique Advantages

• Code Compatibility with M680x0 Family: Maintains object‑code compatibility with MC68020, MC68030 and earlier M68000 processors to ease migration and reuse of existing code.
• Integrated Caches Reduce External Memory Demand: 256‑byte instruction and data caches lower external memory bandwidth needs and help streamline system memory design.
• Flexible Bus and Memory Support: Dynamic bus sizing and burst transfers provide direct interfacing to 8/16/32‑bit devices and efficient DRAM access patterns.
• System Control Features: Access control registers and a pipelined architecture enable controlled cacheability and overlapped execution for predictable performance.
• Package and Assembly Convenience: Delivered in a 132‑CQFP surface‑mount package (24×24) for compact PCB implementations.
• Regulatory Compliance: RoHS compliance supports designs targeting markets with environmental restrictions on lead and certain hazardous substances.

Why Choose MC68EC030FE25C?

The MC68EC030FE25C positions itself as a practical, integration‑focused solution for embedded designs that require M680x0 compatibility, predictable bus behavior, and on‑chip cache resources. Its combination of a 32‑bit 68030 core, integrated caches, dynamic bus sizing, and coprocessor support makes it suitable for developers migrating legacy code or designing compact, performance‑oriented control systems.

This device is well suited to teams and projects that value architectural compatibility, flexible memory interfacing, and the reliability of a processor series designed specifically for embedded control applications. The specified operating range, supply voltage, and surface‑mount packaging support streamlined BOM and PCB implementations in commercial temperature systems.

Request a quote or submit an inquiry to purchase the MC68EC030FE25C and bring this proven 68030‑class embedded controller into your next design.
