MC68EC030CFE25C

The MC68EC030CFE25C is a 32-bit embedded controller based on the 68030 core, implemented as a single 32-bit processor running at 25 MHz and supplied in a 132-pin CQFP (24×24) surface-mount package. It is designed for embedded control applications where integration, legacy M68000-family compatibility, and robust bus interfacing are required.

Series-level design features include on-chip instruction and data caches, a burst-mode bus interface, and dynamic bus sizing for direct interfacing with 8-, 16- and 32-bit memory devices—enabling efficient memory subsystem use and simplified system design.

Key Features

• Core & Architecture 68030 core, single 32-bit processor with object-code compatibility across the M68020/M68030/M68040 instruction sets for straightforward migration of M68000-family software.
• Performance 25 MHz operating frequency for this part; series supports 25- and 40-MHz variants. Designed to maintain performance with cost-effective memory subsystems.
• On-Chip Caches & Memory On-chip data cache (256 bytes) and instruction cache (256 bytes) reduce external memory accesses; 4‑Gbyte direct addressing range simplifies large-memory designs.
• Bus & Memory Interface Burst-mode bus interface and enhanced bus controller supporting asynchronous, synchronous and burst cycles. Dynamic bus sizing allows direct interface to 8-, 16- and 32-bit devices.
• Peripherals & Interfaces Additional SCI interface and full coprocessor support via the M68000 coprocessor interface for expanded system capabilities.
• Power & Technology 5 V I/O voltage; implemented in HCMOS technology for a balance of speed and low power (as described in the series technical data).
• Package & Thermal 132-CQFP (24×24) surface-mount package, industrial qualification with operating temperature range of -40 °C to 85 °C and RoHS compliance.

Typical Applications

• Embedded Control Systems — Use as a central controller for embedded equipment where integrated caches and robust bus control improve responsiveness and simplify memory design.
• Industrial Automation — Suited for industrial control platforms that require an industrial temperature range and durable surface-mount packaging.
• Legacy M68000 Migration — Provides object-code compatibility with M68020/M68030/M68040 series to ease migration of existing M68000-family software.
• Serial Communication Control — Built-in SCI interface supports serial communications tasks within embedded systems and control applications.

Unique Advantages

• Highly Integrated Controller: On-chip instruction and data caches, access control and an improved bus controller reduce external component count and simplify system design.
• Flexible Memory Interfacing: Dynamic bus sizing and burst-mode transfers enable direct connection to a mix of 8-, 16- and 32-bit devices and efficient DRAM access.
• Legacy Compatibility: Object-code compatibility with earlier M68000-family processors eases software migration and protects prior development investments.
• Industrial-Grade Operation: Industrial qualification and an operating range of -40 °C to 85 °C support deployment in temperature-demanding environments.
• Surface-Mount Packaging: 132‑CQFP (24×24) package provides a compact surface-mount option for high-density board designs.
• Standards-Aligned Supply: 5 V I/O and RoHS compliance align the device with common industrial supply rails and environmental requirements.

Why Choose MC68EC030CFE25C?

The MC68EC030CFE25C delivers a balanced combination of 68030-series performance, on-chip cache integration, and flexible bus interfacing tailored for embedded control applications. Its single 32-bit core, support for dynamic bus sizing and burst transfers, and compatibility with the M68000-family instruction set make it a practical choice for systems that require both legacy software continuity and efficient memory subsystem use.

This part is well suited to engineers and procurement teams designing industrial and embedded platforms that prioritize system integration, straightforward memory interfacing, and reliable operation across a wide temperature range. Series-level features such as coprocessor support and nonmultiplexed 32-bit address/data buses support scalable designs and long-term maintainability.

Request a quote or submit a product inquiry to discuss availability, lead time and pricing for the MC68EC030CFE25C.
