MC68EC020FG25

The MC68EC020FG25 is an embedded 32‑bit microprocessor based on the 68020 core, implemented as a single 68020 core running at 25 MHz. It is a second‑generation, enhanced embedded microprocessor intended for embedded and consumer systems.

Designed for board‑level integration, the device offers a standard 100‑pin QFP package, 5 V I/O signaling and surface‑mount mounting, making it suitable for integration into a range of consumer and embedded designs that operate within a 0 °C to 70 °C temperature range.

Key Features

• Core  The MC68EC020 implements the 68020 core as a single 32‑bit processor core.
• Clock Speed  Operates at 25 MHz for deterministic processing in embedded applications.
• Voltage I/O  5 V I/O signaling to match legacy and standard embedded system voltage domains.
• Package & Mounting  Available in a 100‑pin BQFP / 100‑QFP (14×20) package with surface‑mount assembly for compact PCB layouts.
• On‑chip Cache Memory  Includes on‑chip cache memory as documented in the device user manual to improve instruction throughput.
• Coprocessor Interface  Supports a coprocessor interface as described in the device documentation for system expansion.
• Consumer Qualification  Device is qualified for consumer applications and operates over 0 °C to 70 °C.
• Regulatory Compliance  RoHS compliant for environmental and manufacturing considerations.
• Graphics Acceleration  No graphics acceleration — suitable for control, processing and legacy embedded workloads.

Typical Applications

• Embedded Consumer Systems  Integration into consumer‑grade embedded devices requiring a 32‑bit processing core and standard 5 V I/O.
• Embedded Control and Automation  Deterministic 25 MHz operation for control logic, sequencing and system management in embedded controllers.
• Board‑Level Integration  Surface‑mount 100‑QFP package suited for compact PCB designs and module replacements.
• Development and Evaluation  Use in prototyping and evaluation of 68020‑based architectures and legacy designs.

Unique Advantages

• 32‑Bit Processing Capability: Provides a full 32‑bit core for wider data paths and addressability compared with earlier 16‑bit designs.
• Standard I/O Voltage: 5 V I/O simplifies integration with existing embedded boards and legacy peripherals.
• Compact Surface‑Mount Package: 100‑QFP (14×20) package enables dense board layouts and straightforward surface‑mount assembly.
• On‑Chip Cache: Built‑in cache memory helps improve instruction execution efficiency as described in the device documentation.
• Documented Expansion Interface: Coprocessor interface support provides a path for system expansion and specialized processing.
• RoHS Compliant: Environmentally compliant manufacturing support for modern production requirements.

Why Choose MC68EC020FG25?

The MC68EC020FG25 positions itself as a practical 32‑bit embedded microprocessor for consumer and embedded applications that require a proven 68020 architecture, a 25 MHz operating speed, and standard 5 V I/O. Its surface‑mount 100‑QFP package and on‑chip features make it straightforward to integrate into board‑level designs where deterministic processing and ease of assembly are priorities.

This device suits designers maintaining or developing 68020‑based systems who need documented behavior (see the device user manual) and standard packaging for compact layouts. RoHS compliance and consumer qualification support production and deployment in consumer embedded products within the specified 0 °C to 70 °C operating range.

Request a quote or submit an inquiry to receive pricing, availability and the full technical datasheet for MC68EC020FG25.
