MC68EC060RC75

The MC68EC060RC75 is a single-core 32-bit microprocessor in the MC68EC060 family, featuring a 68060 core running at 75 MHz. Designed for embedded applications, it combines a mature 68060 architecture with standard 3.3 V I/O and a through-hole 206‑PGA package to support systems-level integration and hardware maintenance.

Typical uses include embedded control and communications equipment where a compact, socketable 206‑PGA package and SCI serial interface simplify board-level integration and serviceability.

Key Features

• Core and Performance 68060 core processor implemented as a single 32‑bit core running at 75 MHz for deterministic embedded processing.
• Voltage and I/O 3.3 V I/O level suitable for common embedded logic domains.
• Package and Mounting 206‑PGA supplier device package (47.25×47.25 mm) in a through‑hole mounting format for socketed or board-level installations.
• Interfaces Includes an SCI serial communications interface for standard serial peripheral connectivity.
• Operating Range Rated for operation from 0 °C to 70 °C to match many commercial embedded environments.
• Environmental Compliance RoHS compliant to support environmentally conscious designs and sourcing.

Typical Applications

• Embedded controllers — Use the 32‑bit 68060 core and 75 MHz operation for control tasks and system management in embedded devices.
• Industrial automation — Through‑hole 206‑PGA packaging facilitates replacement and maintenance in industrial control modules.
• Communications equipment — SCI interface enables serial connectivity for modem, terminal, or peripheral interface roles.
• Legacy and retrofit systems — Package and mounting style support integration into existing boards and socketed designs requiring a 206‑PGA form factor.

Unique Advantages

• Proven 68060 architecture: Delivers a 32‑bit processing core familiar to embedded designers working with the M680x0 family.
• Socketable 206‑PGA package: 206‑PGA (47.25×47.25 mm) through‑hole format supports socketed deployment and field replaceability.
• 75 MHz clock rate: Provides deterministic execution suitable for timing‑sensitive embedded tasks.
• 3.3 V I/O compatibility: Matches common logic levels for straightforward system interfacing.
• Integrated serial interface (SCI): Built‑in SCI eases implementation of serial communications without adding external UART components.
• RoHS compliant: Meets environmental compliance requirements for regulated markets.

Why Choose MC68EC060RC75?

The MC68EC060RC75 positions a single 68060 32‑bit core at 75 MHz within a serviceable 206‑PGA through‑hole package, making it suitable for embedded designs that require a balance of processing capability, standard I/O voltage, and field maintainability. Its SCI interface and 3.3 V I/O levels simplify integration into existing embedded systems.

Backed by the MC68060 family documentation, the MC68EC060RC75 is appropriate for engineers and procurement teams targeting commercial-temperature, socketable microprocessor solutions where long-term availability and clear documentation are important for system lifecycle planning.

Request a quote or submit a parts inquiry to initiate pricing and availability for the MC68EC060RC75.
