MC68HC000FN16R2

The MC68HC000FN16R2 is a single-core 32-bit microprocessor based on the EC000 core, manufactured by NXP Semiconductors as part of the MC68HC000 series. It operates at 16 MHz with 5 V I/O and is offered in a 68‑pin PLCC surface‑mount package (24.21 × 24.21 mm), targeted for consumer-grade embedded applications.

This device is suitable for designs that require a compact surface-mount 32-bit processor with defined operating conditions and RoHS compliance. Its specification set supports straightforward integration into legacy and new embedded systems that use the M680x0 family architecture.

Key Features

• Core and Performance — EC000 single 32‑bit core running at a fixed 16 MHz clock frequency, providing a consistent processing baseline for embedded tasks.
• Voltage and I/O — 5 V I/O compatibility to match legacy 5 V system interfaces and peripheral devices.
• Package and Mounting — 68‑pin PLCC (68‑LCC J‑Lead) surface‑mount package with supplier dimensions 24.21 × 24.21 mm for compact board layouts.
• Operating Range — Rated for consumer qualification with an operating temperature range of 0 °C to 70 °C.
• Environmental Compliance — RoHS compliant, supporting regulatory requirements for lead‑free assembly.
• Graphics — No dedicated graphics acceleration, simplifying integration when standalone processor control is required.

Typical Applications

• Consumer Electronics — Control and processing in consumer devices where a 32‑bit EC000 core and 5 V I/O are required.
• Legacy System Maintenance — Replacement or support of existing M680x0‑family designs that rely on the MC68HC000 series architecture.
• Embedded Development & Prototyping — Development platforms and educational projects leveraging a single 32‑bit core with straightforward power and temperature requirements.

Unique Advantages

• MC68HC000 Series Proven Architecture — Part of the MC68HC000/M68000 family lineage referenced in the M68000 user manual, enabling familiar programming and architecture characteristics for engineers working with this family.
• Compact PLCC Surface‑Mount Package — 68‑pin PLCC (24.21 × 24.21 mm) reduces board footprint while providing accessible pinout for embedded designs.
• 5 V System Compatibility — Native 5 V I/O eases integration with legacy peripherals and existing system rails.
• RoHS Compliant — Meets lead‑free assembly requirements for modern manufacturing processes.
• Consumer‑Grade Operating Range — Specified 0 °C to 70 °C range for typical consumer environments and product applications.
• Straightforward Integration — Single‑core, no graphics acceleration simplifies firmware and hardware partitioning for control‑centric applications.

Why Choose MC68HC000FN16R2?

MC68HC000FN16R2 delivers a practical, well‑defined 32‑bit EC000 core solution in a compact PLCC surface‑mount package, suited to consumer embedded designs and projects that align with the M680x0 family architecture. Its 16 MHz clocking, 5 V I/O, and RoHS compliance make it a direct choice for systems requiring compatibility with legacy interfaces and lead‑free manufacturing.

This device is appropriate for engineers and procurement teams seeking a stable, consumer‑qualified microprocessor for board‑level integration, maintenance of M68000‑series platforms, or development of control‑focused embedded products.

Request a quote or submit an inquiry for availability, lead time, and volume pricing for MC68HC000FN16R2 to receive further purchasing information and support.
