MC68VZ328VP

The MC68VZ328VP from NXP Semiconductors is a FLX68000-based microprocessor offering a single 32‑bit core running at 33 MHz in a compact 144‑MAPBGA (13×13) surface‑mount package. It is part of the MC68VZ328 (DragonBall VZ) family and is supplied in tray packaging.

Designed for embedded and portable systems, the device integrates memory controllers for SDRAM and DRAM, peripheral interfaces such as PWM, and a System Integration Module to reduce external glue logic and board space. The device’s static core and 3 V I/O support lower-power operation and system-level flexibility.

Key Features

• Core  FLX68000 static CPU core; single 32‑bit core providing the architecture foundation for embedded designs.
• Clock and Performance  33 MHz processor clock. Datasheet notes a static core design with 5.4 MIPS performance at 33 MHz.
• Memory and Controllers  On‑chip memory controller functions with support for SDRAM and DRAM; documented glueless interface options to SRAM, DRAM, SDRAM, EPROM, and FLASH.
• Peripherals and Interfaces  Integrated peripherals include UART (with IrDA 1.0 in the family description), SPI with FIFO, 16‑bit timers and PWM outputs for common embedded control tasks.
• System Integration Module (SIM)  Integrated SIM provides system configuration, programmable address mapping and other functions to reduce external array logic and parts count.
• Power and I/O  Static core allows the processor clock to be stopped for power savings; specified I/O voltage of 3 V.
• Package and Mounting  144‑MAPBGA (13×13) supplier device package; surface‑mount assembly, shipped in tray format.

Typical Applications

• Portable/Handheld Devices  Well suited for PDAs and other handhelds where compact packaging and integrated peripherals reduce BOM and board area.
• Consumer Fitness and Wearables  Applicable to exercise monitors and similar portable consumer devices requiring integrated memory support and low‑power operation.
• Navigation and Location Devices  Suitable for navigation systems that benefit from on‑chip memory controllers and serial interfaces for sensor and display connectivity.
• Smart Mobile Devices  Appropriate for smart phone and related portable designs leveraging integrated system functions and compact BGA packaging.

Unique Advantages

• Highly integrated System Integration Module: Reduces external glue logic and parts count by consolidating configuration and address mapping.
• Glueless memory interfaces: Simplifies board design with direct support for SRAM, DRAM, SDRAM, EPROM and FLASH memory types.
• Static FLX68000 core with clock‑stop capability: Enables power savings in low‑activity or battery‑powered applications.
• Compact BGA footprint: 144‑MAPBGA (13×13) package minimizes PCB area for dense, space‑constrained designs.
• 3 V I/O compatibility: Matches common low‑voltage system environments for modern embedded applications.

Why Choose MC68VZ328VP?

The MC68VZ328VP positions itself as a compact, integrated microprocessor option for embedded and portable designs that require a 32‑bit FLX68000 core, on‑chip memory controller support, and a suite of serial and timer peripherals. Its static core architecture and glueless memory interfaces help simplify system design while reducing board space and external component count.

Choose this device when your project needs a proven FLX68000 family derivative in a surface‑mount BGA package with 3 V I/O, SDRAM/DRAM controller support, and integrated system functions for streamlined hardware design.

Request a quote or submit an inquiry to discuss availability, lead times and pricing for the MC68VZ328VP.
