MCIMX351AJQ5C

The MCIMX351AJQ5C is an i.MX35 series microprocessor featuring an ARM1136JF-S single 32‑bit core running at 532 MHz in a 400‑LFBGA (17 × 17 mm) package. It targets embedded designs that require integrated multimedia and connectivity capabilities with industrial qualification and a wide operating temperature range.

Built for systems that combine audio, display and network interfaces, this device provides a compact, single‑chip processing solution with on‑chip peripherals and security features to simplify system design and accelerate time to market.

Key Features

• Core ARM1136JF‑S single 32‑bit core operating at 532 MHz, providing deterministic processing for embedded multimedia and control tasks.
• Co‑processors Multimedia and VFP co‑processors for enhanced media handling and floating‑point operations.
• Memory Interfaces Integrated controllers for LPDDR and DDR2 memory to support system memory configurations.
• Display & Input On‑chip display interface controllers including LCD and keypad (KPP) controllers for user interface designs.
• Connectivity Single 10/100 Mbps Ethernet interface and two USB 2.0 ports with PHY for wired networking and high‑speed peripheral connectivity.
• Security Secure Fusebox and Secure JTAG features to support device security and controlled debug access.
• Package & Mounting 400‑LFBGA package (17 × 17 mm, 0.8 mm pitch), surface mount for compact board implementations.
• Additional Interfaces 1‑Wire interface for simple sensor or accessory connections.
• Operating Range & Qualification Industrial qualification and an operating temperature range of −40 °C to 85 °C for deployment in demanding environments.
• Graphics Note: Graphics acceleration is not provided in this device.

Typical Applications

• Multimedia & Audio Systems Use the integrated multimedia co‑processor and audio connectivity features for playback, speech processing and audio interface applications.
• Navigation & Display Devices Drive LCD displays and implement route calculation or map presentation in embedded navigation and display solutions.
• Human‑Machine Interfaces (HMI) Combine the keypad and LCD controllers with the ARM core to implement responsive HMIs and control panels.
• Networked Embedded Appliances Leverage the 10/100 Ethernet and USB 2.0 interfaces for connected devices requiring wired networking and peripheral connectivity.

Unique Advantages

• Integrated multimedia capability: On‑chip multimedia co‑processor and VFP accelerate audio and media processing without adding external accelerators.
• Flexible memory support: LPDDR and DDR2 controllers enable designers to choose memory types that match performance and cost targets.
• Broad interface set: Ethernet, dual USB 2.0 with PHY and 1‑Wire simplify external connectivity and reduce additional components.
• Robust operating range: Industrial qualification and −40 °C to 85 °C temperature rating support reliable operation across harsh environments.
• Hardware security primitives: Secure Fusebox and Secure JTAG provide foundations for protecting code and controlling debug access.
• Compact packaging: 400‑LFBGA (17 × 17 mm) enables dense board layouts for space‑constrained systems.

Why Choose MCIMX351AJQ5C?

The MCIMX351AJQ5C balances a 532 MHz ARM1136JF‑S core with integrated multimedia, memory controllers and connectivity to deliver a compact, capable platform for embedded multimedia and networked applications. Its industrial qualification and wide temperature range make it suitable for robust designs that require dependable operation.

This part is well suited for engineers building systems that require integrated audio, display and wired connectivity while minimizing external component count. Comprehensive documentation and datasheet resources support development and system integration.

If you would like pricing or availability for MCIMX351AJQ5C, request a quote or submit an inquiry for a formal quote and technical information.
