MCIMX6S5EVM10AB

The MCIMX6S5EVM10AB is a single‑core ARM® Cortex®‑A9 microprocessor from the i.MX 6S series operating at 1.0 GHz. Designed as a multimedia-focused embedded MPU, it pairs a 32‑bit Cortex‑A9 core with integrated graphics and video processing and on-chip power management to address cost- and power-sensitive designs.

Targeted use cases include web and multimedia tablets and consumer multimedia products where integrated interfaces, graphics acceleration and robust connectivity are required. The device delivers a balanced mix of performance, integration and system-level features for embedded and consumer applications.

Key Features

• Core and Performance  ARM® Cortex®‑A9 single core running at 1 GHz with a 32‑bit bus width for general embedded processing tasks.
• Memory Interface  Supports LPDDR2, LVDDR3 and DDR3 memory controllers to match common board memory choices.
• Graphics and Video  Includes 2D and 3D graphics processors and 1080p video processing capabilities; graphics acceleration is provided.
• Connectivity  Integrated 10/100/1000 Mbps Ethernet (1), four USB 2.0 ports with PHY and CAN interface support for networking and peripheral connectivity.
• Security  Comprehensive on‑chip security features including ARM TrustZone, boot security, cryptography, RTIC, secure fusebox, secure JTAG, secure memory and secure RTC with tamper detection.
• Display and HMI  Built‑in display interface controllers including LCD and keypad support for user interface implementations.
• Power and Integration  Integrated power management features and on-chip regulators referenced in the datasheet to simplify system power design.
• Package and Mounting  624‑MAPBGA (21 × 21 mm, 0.8 mm pitch) plastic BGA package, surface mount.
• Operating Range  Operational temperature range from −20 °C to 105 °C for a broad set of ambient environments.

Typical Applications

• Web and multimedia tablets  Delivers processing, graphics and video capabilities for tablet-class user experiences.
• Consumer multimedia devices  Suitable for consumer-focused products that require integrated video processing and graphics acceleration.
• HMI and display systems  LCD and keypad controllers support human‑machine interface applications and embedded displays.
• Networked embedded products  Gigabit Ethernet, multiple USB ports and CAN enable connectivity in connected consumer and embedded devices.

Unique Advantages

• Multimedia‑focused architecture: 2D/3D graphics and 1080p video processing provide the building blocks for rich user interfaces and video playback.
• Flexible memory options: Support for LPDDR2, LVDDR3 and DDR3 memory types allows designers to choose memory that fits performance and cost targets.
• Comprehensive security suite: Multiple on‑chip security features reduce the need for external security components and help protect boot and runtime operation.
• Integrated connectivity: Built‑in Gigabit Ethernet, multiple USB 2.0 with PHY and CAN reduce BOM complexity for networked embedded systems.
• System integration and power management: On‑chip power management and integrated regulator features help simplify board power design and lower system-level power consumption.
• Robust thermal range: −20 °C to 105 °C operating range supports deployment across a wide set of environmental conditions.

Why Choose MCIMX6S5EVM10AB?

The MCIMX6S5EVM10AB positions as a balanced, multimedia‑focused MPU within the i.MX 6S series—combining a 1.0 GHz Cortex‑A9 core with graphics acceleration, broad memory support and integrated connectivity. Its security features and on‑chip power management streamline system design for consumer and embedded multimedia products.

As part of the i.MX 6S family from NXP Semiconductors, this part is suited for engineers developing web and multimedia tablets, consumer multimedia devices, HMI and networked embedded systems who need an integrated platform with proven multimedia and interface capabilities.

Request a quote or submit a purchase inquiry to evaluate the MCIMX6S5EVM10AB for your next embedded multimedia design.
