Z8018006VEC

The Z8018006VEC is a Zilog Z80180 microprocessor IC featuring a single 8-bit core running at 6 MHz. Designed for embedded and industrial applications, it integrates a Z80180 core with on-chip DRAM controller support and ASCI serial interface functionality.

Key attributes include 5 V I/O signaling, a surface-mount 68-PLCC (68-LCC J-lead) package, and an industrial operating temperature range of -40°C to 100°C, making it suitable for robust embedded systems requiring wide-temperature operation and through-life availability.

Key Features

• Core & Architecture Z80180 core, single 8-bit processor core providing legacy-compatible microprocessor functionality.
• Clock Speed 6 MHz operating speed for deterministic control tasks and embedded processing.
• Power and I/O 5 V I/O voltage compatibility for interfacing with conventional TTL/CMOS logic levels.
• Memory Support Integrated DRAM controller support to simplify external memory interfacing and system design.
• Interfaces ASCI serial interface available for serial communications and peripheral connectivity.
• Package & Mounting 68-PLCC (68-LCC, J-lead) surface-mount package for compact PCB layouts and automated assembly.
• Industrial Temperature Range Rated for operation from -40°C to 100°C to meet industrial environmental requirements.
• RoHS Compliant Meets RoHS environmental requirements for lead-free assembly processes.

Typical Applications

• Industrial Control — Control logic and peripheral interfacing in industrial automation where wide temperature range and reliable 5 V I/O are required.
• Embedded Systems — Core microprocessor for embedded products needing an 8-bit Z80180 architecture with DRAM controller support.
• Instrumentation — Embedded measurement and data-acquisition controllers benefitting from deterministic 6 MHz operation and serial ASCI connectivity.
• Legacy and Maintenance — Replacement or sustainment of existing Z180-based designs that require a surface-mount 68-PLCC package and industrial-grade operation.

Unique Advantages

• Industrial-grade temperature specification: Specified for -40°C to 100°C operation to suit harsh and temperature-variable environments.
• On-chip DRAM controller: Reduces external memory interface complexity and supports straightforward system memory integration.
• 5 V I/O compatibility: Simplifies interconnection with established TTL/CMOS peripherals and legacy modules.
• ASCI serial interface: Provides built-in serial communication capability for peripheral and communication link implementations.
• Surface-mount 68-PLCC package: Compact, assembly-friendly package for dense PCB designs and automated production.
• RoHS compliant: Complies with environmental lead-free requirements for modern electronics manufacturing.

Why Choose Z8018006VEC?

The Z8018006VEC positions the Z80180 core in a compact, industrial-grade surface-mount package, combining established 8-bit processing with DRAM controller and serial interface integration. Its 6 MHz operating speed and 5 V I/O make it a practical choice for embedded designs that need predictable control performance and straightforward peripheral interfacing.

Backed by Zilog's Z80180 family architecture, this part is suited to designers and manufacturers maintaining or building embedded and industrial equipment where temperature range, package density, and standard I/O signaling are key selection criteria.

Request a quote or submit a purchase inquiry for Z8018006VEC today to discuss availability and pricing for your next embedded or industrial design.
