Z8018010VSG00TR

The Z8018010VSG00TR is a Zilog Z80180 microprocessor IC featuring a single Z80-compatible 8-bit core running at 10 MHz. Designed for embedded applications, it integrates core processing functionality with on-chip support for DRAM and a standard 5 V I/O interface.

This commercial-grade device comes in a 68-lead PLCC surface-mount package and targets embedded system designers who require a compact, proven 8-bit processor with basic memory controller and serial interface capabilities.

Key Features

• Core Z80180 single 8-bit core running at 10 MHz, providing deterministic control for embedded tasks.
• Memory Support Integrated DRAM controller capability to simplify external memory interfacing and system design.
• Power and I/O 5 V I/O voltage for compatibility with legacy 5 V logic domains.
• Interfaces Includes ASCI additional interface for serial communications integration.
• Package and Mounting Available in a 68-PLCC supplier device package (24.23×24.23 mm) with a 68-LCC (J‑Lead) package case; surface-mount mounting type for PCB assembly.
• Operating Range Commercial operating temperature range from 0 °C to 70 °C, suitable for standard indoor and office environments.
• Compliance RoHS compliant, aligning with common environmental requirements.

Typical Applications

• Embedded systems General-purpose control and processing in embedded designs that benefit from an 8-bit Z80180 core and DRAM support.
• Consumer electronics Control and interface tasks in consumer devices that operate within commercial temperature ranges and 5 V logic domains.
• Instrumentation and test equipment Deterministic 8-bit processing for measurement, control, and user-interface handling in benchtop instruments.

Unique Advantages

• Single-core deterministic processing: The Z80180 8-bit core at 10 MHz provides predictable timing for control-oriented embedded tasks.
• Integrated DRAM controller: Reduces external memory glue logic and simplifies system memory architecture.
• Standard 5 V I/O: Eases interfacing with legacy 5 V peripherals and existing board-level designs.
• Compact PLCC surface-mount package: 68-PLCC (24.23×24.23 mm) footprint supports high-density board layouts and automated assembly.
• Commercial-grade suitability: Rated for 0 °C to 70 °C operation, appropriate for typical indoor and consumer environments.
• RoHS compliant: Meets common environmental compliance requirements for modern electronic products.

Why Choose Z8018010VSG00TR?

The Z8018010VSG00TR positions itself as a compact, integrated solution within the Z180 (Z80180) family for embedded designers needing an 8-bit Z80-compatible core with on-chip DRAM control and standard 5 V I/O. Its combination of a 10 MHz clock, ASCI interface, and PLCC surface-mount packaging makes it suitable for systems where proven 8-bit processing and straightforward memory interfacing are priorities.

Ideal for developers of embedded control, consumer products, and instrumentation that operate in commercial environments, this Zilog microprocessor offers a balance of integration and familiar voltage-domain compatibility that supports stable, maintainable designs over product life cycles.

Request a quote or submit an inquiry to receive pricing and availability for Z8018010VSG00TR and to discuss how this Z80180 device can fit into your next embedded design.
