AGL125V5-CSG196

The AGL125V5-CSG196 is an IGLOO Field Programmable Gate Array (FPGA) from Microchip Technology providing 3,072 logic elements and 36,864 bits of on-chip RAM. It delivers a compact, surface-mount FPGA solution in a 196-TFBGA/CSBGA package targeted at commercial-temperature designs.

With 133 I/O, an internal gate count of 125,000, and a defined single-supply voltage range, this FPGA is suited to embedded logic implementations that require a balance of logic capacity, on-chip memory, and a space-efficient package.

Key Features

• Logic Capacity — 3,072 logic elements (cells) supporting medium-density programmable logic implementations.
• Embedded Memory — 36,864 bits of on-chip RAM (approximately 36.9 kbits) for local buffering, state storage, or small data structures.
• I/O — 133 general-purpose I/O pins to interface with external peripherals, sensors, and buses.
• Gate Count — Approximately 125,000 gates to quantify overall logic resources available for design partitioning.
• Power — Single-supply operation within a defined range of 1.425 V to 1.575 V for consistent power planning and voltage domain integration.
• Package & Mounting — Available in a 196-TFBGA, CSBGA package (supplier device package: 196-CSP 8×8) with surface-mount mounting for compact PCB integration.
• Temperature & Grade — Commercial-grade operation specified from 0 °C to 70 °C for typical commercial environments.
• Compliance — RoHS-compliant to support regulated manufacturing and assembly processes.

Unique Advantages

• Balanced Logic and Memory: 3,072 logic elements paired with 36,864 bits of on-chip RAM enable compact implementation of control and data-path functions without requiring large external memory.
• Generous I/O Count: 133 I/O pins simplify interfacing multiple peripherals or parallel buses, reducing external glue logic.
• Defined Supply Window: The specified 1.425 V to 1.575 V supply range makes power-supply design predictable and repeatable.
• Compact Surface-Mount Package: The 196-TFBGA (196-CSP 8×8) package supports high-density board layouts and helps minimize PCB footprint.
• Commercial Temperature Suitability: Rated for 0 °C to 70 °C operation, appropriate for a wide range of commercial applications.
• Regulatory Compliance: RoHS compliance assists in meeting environmental and manufacturing requirements.

Why Choose AGL125V5-CSG196?

The AGL125V5-CSG196 delivers a practical mix of logic density, embedded memory, and I/O capability in a compact surface-mount package from Microchip Technology. Its clearly specified supply voltage and commercial temperature range make it straightforward to integrate into many standard embedded designs where moderate logic resources and on-chip RAM are required.

This FPGA is well suited for designers and procurement teams seeking a medium-density, RoHS-compliant programmable-logic device in a space-efficient 196-TFBGA footprint. The combination of logic elements, I/O count, and gate capacity supports a wide range of control, interfacing, and data-path tasks while simplifying PCB integration.

Request a quote or submit an inquiry to check availability and pricing for the AGL125V5-CSG196 and discuss how it can meet your design requirements.
